INTRODUCTION
SOFTWARE/HARDWARE CONFIGURATIONS
1.8 Technical Reference Manual Chapter Issue 12, Feb 18
Software Release Version 9 SP04
Software
Hardware
Software Release Version 9 SP05
Software
Hardware
Feature Detail
Defect Fixes Various
Feature Detail
Printer Covers Introduction to the new look iX printers
Rapid Transit Conveyor The Rapid Transit Conveyor (RTC) module can accom-
modate up to three boards in the printer at a time; this
reduces the printer cycle time
Feature Detail
Defect Fixes Various
Feature Detail
Modular Transport Rails Introduction to the modular transport rail system. This
rail system allows modules to be changed without hav-
ing to replace the complete assembly. Modularity can
support a variety of tooling and clamping arrangements;
the current module is: Over the Top Snuggers (see
below)
Over the Top Snuggers Substrate clamping arrangement to hold the substrate
flat to enable good tooling contact. The over the top
clamp is withdrawn to provide a flat surface for printing
Programmable Beacon Instruction on how to set up and use the programmable
beacon
Print Roll Height Monitor The roll height monitor measures the height of the paste
roll to give system feedback for replenishment.
INTRODUCTION
SOFTWARE/HARDWARE CONFIGURATIONS
Chapter Issue 12, Feb 18 Technical Reference Manual 1.9
Software Release Version 9 SP06
Software
Hardware
Software Release Version 9 SP07
Software
Hardware
Feature Detail
Defect Fixes Various
Feature Detail
Modular Transport Rails Update to the modular transport rail system. This rail
system allows tooling modules to be changed without
having to replace the complete transportation assem-
bly. Includes information on the modular version of the
High Throughput Conveyor (HTC) system.
Feature Detail
Defect Fixes Various
Feature Detail
ProFlow Tx The evolution of ProFlow - Enclosed printing, widens
the performance envelope.
ProFlow ATx Advanced ProFlow system, single cartridge, active
paste handling.
Over the Top Snuggers Additional snugging module for the modular transport
rail system.
Print Roll Height Monitor Upgrade to the paste roll height monitoring system.
ProActiv Module Active squeegees to enhance paste deposition.
Remote Barcode Reader New reader - replaces the existing unit with more func-
tionality.
INTRODUCTION
SOFTWARE/HARDWARE CONFIGURATIONS
1.10 Technical Reference Manual Chapter Issue 12, Feb 18
Software Release Version 9 SP08
Software
Hardware
Software Release Version 9 SP09
Software
Hardware
Software Release Version 9 SP10
Software
Hardware
Feature Detail
Stinger Adhesive dot dispensing module option
Defect Fixes Various
Feature Detail
Stinger Adhesive deposition module option
Verification and Traceability Rationalisation of capabilities with a single barcode
reader for 1D and 2D
Underscreen cleaner Enhanced cleaning capabilities
Magna Print Magnetic squeegee application
Feature Detail
Defect Fixes Various
Feature Detail
Heavy Pallet Rails Option not featured; a stand-alone manual exists
Feature Detail
Stinger Auto calibration and purging routines
Defect Fixes Various
Feature Detail
Stinger Purge pot
