SAFETY FEATURES
PRINTER SAFETY FEATURES
2.4 Technical Reference Manual Chapter Issue 14, Feb 18
CAUTION
SOLVENT SOLUTION. DO NOT MIX SOLVENT SOLUTIONS. FLUSH
THE SOLVENT TANK THOROUGHLY WHEN CHANGING TO A DIF-
FERENT SOLVENT SOLUTION.
CAUTION
ANTI- STATIC HANDLING. STANDARD PRECAUTIONS MUST BE
ADHERED TO WHEN HANDLING ELECTRONIC CARDS AND CON-
FIGURING AND INSERTING INTO THE ENCLOSURES.
CAUTION
RADIATION. RISK OF INJURY TO THE EYES DUE TO LASER LIGHT
BEING PRESENT IN THE VICINITY OF THE LABEL. DO NOT LOOK
AT THE LIGHT SOURCE OR REFLECTIONS FROM A SURFACE.
CAUTION
EQUIPMENT SERVICING. THE LASER DOES NOT CONTAIN USER
SERVICEABLE PARTS. OPENING THE UNIT COULD CAUSE MIS-
ALIGNMENT OF THE LASER, THIS MAY MAKE THE EQUIPMENT
DANGEROUS TO OPERATE.
CAUTION
LASER CONTROLS AND ADJUSTMENTS. USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE.
SYMBOL DEFINITION
SAFETY FEATURES
PRINTER SAFETY FEATURES
Chapter Issue 14, Feb 18 Technical Reference Manual 2.5
Mandatory Notices Mandatory notices draw the attention of users/maintainers to the prescribed
behaviour to be adhered whilst engaged in this activity. The following table
displays the mandatory labels affixed to the printer and displayed in the printer
documentation:
SYMBOL DEFINITION
MANDATORY
TOXIC CHEMICALS MAY BE PRESENT. SAFETY GLOVES MUST BE
WORN.
MANDATORY
TOXIC CHEMICALS MAY BE PRESENT. EYE PROTECTION MUST BE
WORN
MANDATORY
HEAVY OBJECT. LIFTING OR RESITING MUST BE UNDERTAKEN BY
TWO PEOPLE.
SAFETY FEATURES
PRINTER SAFETY FEATURES
2.6 Technical Reference Manual Chapter Issue 14, Feb 18
SEMI Labelling The following table displays the SEMI labelling that may be applied to the
printer:
WARNING DEFINITION LOCATION
MOVING MECHANICAL PARTS
REMOVING THIS COVER EXPOSES
MOVING MECHANICAL PARTS THAT
HAVE THE POTENTIAL TO CAUSE
SERIOUS INJURY. DISCONNECT
AND LOCK OUT THE SYSTEM
POWER BEFORE REMOVING THIS
COVER. REFER TO THE LOCKOUT
PROCEDURE AT THE END OF THIS
CHAPTER.
GENERAL WARNING
REFER TO THE OPERATOR MANUAL
OR THE FRONT OF THIS CHAPTER
FOR A LIST OF ALL WARNINGS AND
THEIR DEFINITIONS.
LEFT HAND UPPER
SIDE PANEL
MOVING MECHANICAL PARTS
REMOVING THIS COVER EXPOSES
MOVING MECHANICAL PARTS THAT
HAVE THE POTENTIAL TO CAUSE
SERIOUS INJURY. DISCONNECT
AND LOCK OUT THE SYSTEM
POWER BEFORE REMOVING THIS
COVER. REFER TO THE LOCKOUT
PROCEDURE AT THE END OF THIS
CHAPTER.
STRONG MAGNETIC FIELD
A STRONG MAGNETIC FIELD EXISTS
IN THE VICINITY OF THE CAMERA
LINEAR MOTORS. THESE MAY REP-
RESENT A SERIOUS HAZARD TO
PEOPLE FITTED WITH A PACE-
MAKER.
GENERAL WARNING
REFER TO THE OPERATOR MANUAL
OR THE FRONT OF THIS CHAPTER
FOR A LIST OF ALL WARNINGS AND
THEIR DEFINITIONS.
RIGHT HAND
UPPER SIDE
PANEL
WARNING / DANGER
Pièces mécaniques en mouvement
Retirer les capots ou couvercles
peut entraîner des blessures graves.
Déconnecter et couper l alimentation
électrique avant deffectuer lentretien
de la machine, se référer au
Manuel de Référence Technique.
Pièces mécaniques en mouvement
Retirer les capots ou couvercles
peut entraîner des blessures graves.
Déconnecter et couper l alimentation
électrique avant deffectuer lentretien
de la machine, se référer au
Manuel de Référence Technique.
Moving Mechanical Parts
Removing covers could result
in serious injury
Disconnect and lockout system power
before servicing refer to the
Technical Reference manual
Moving Mechanical Parts
Removing covers could result
in serious injury
Disconnect and lockout system power
before servicing refer to the
Technical Reference manual
Pièces mécaniques en mouvement
Retirer les capots ou couvercles
peut entraîner des blessures graves
Déconnecter et couper l alimentation
électrique avant deffectuer lentretien
de la machine
Pièces mécaniques en mouvement
Retirer les capots ou couvercles
peut entraîner des blessures graves
Déconnecter et couper l alimentation
électrique avant deffectuer lentretien
de la machine
Moving Mechanical Parts
Removing covers could result
in serious injury
Disconnect and lock out system power
before servicing
Moving Mechanical Parts
Removing covers could result
in serious injury
Disconnect and lock out system power
before servicing
WARNING / DANGER
An electromagnetic field exists
within the machine from the camera
linear motors.
These may present a hazard to people
fitted with an implanted cardiac device.
The motor manufacturer recommends
a safe distance of at least 15mm.
An electromagnetic field exists
within the machine from the camera
linear motors.
These may present a hazard to people
fitted with an implanted cardiac device.
The motor manufacturer recommends
a safe distance of at least 15mm.
Electro Magnetic Field
Refer to the Operator and
Technical Reference manuals
Refer to the Operator and
Technical Reference manuals
Reportez-vous aux Manuel Opérateur
et de Référence Technique.
Reportez-vous aux Manuel Opérateur
et de Référence Technique.
Champ Electromagnétique
Les moteurs linéaires présents dans
la machine créent un champ
électromagnétique. Celui-ci peut
présenter des dangers pour les
personnes portant un stimulateur
ou dispositif cardiaque implanté.
Le fabricant recommande une
distance de sécurité dau moins 15mm.
Champ Electromagnétique
Les moteurs linéaires présents dans
la machine créent un champ
électromagnétique. Celui-ci peut
présenter des dangers pour les
personnes portant un stimulateur
ou dispositif cardiaque implanté.
Le fabricant recommande une
distance de sécurité dau moins 15mm.
