Station Softw are V ersion 710.0 (R16 - 2) Softw are V ersion Descripti on Stationssof tware - V ersion 710.0 (R16 - 2) Sof tw ar e - V ersionsbeschrei bung A usgabe 12/2016 Edition

Station Software Version 710.0 (R16-2)

Software Version Description

Stationssoftware-Version 710.0 (R16-2)

Software-Versionsbeschreibung

Ausgabe 12/2016 Edition

All names identified by ® are registered trademarks of the ASM Assembly Systems GmbH & Co. KG. The

remaining trademarks in this publication may be trademarks whose use by third parties for their own purposes

could violate the rights of the owner.

We have reviewed the contents of this publication to ensure consistency with the hardware and software

described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the

information given in this publication is reviewed regularly and any necessary corrections are included in

subsequent editions.

ASM Assembly Systems GmbH & Co. KG Item-no.: 00198235-01

Rupert-Mayer-Strasse 44

81379 München

Germany

www.asm-smt.com

Alle mit dem Schutzrechtsvermerk ® gekennzeichneten Bezeichnungen sind eingetragene Marken der ASM

Assembly Systems GmbH & Co. KG. Die übrigen Bezeichnungen in dieser Schrift können Marken sein, deren

Benutzung durch Dritte für deren Zwecke die Rechte der Inhaber verletzen kann.

Wir haben den Inhalt der Druckschrift auf Übereinstimmung mit der beschriebenen Hard- und Software geprüft.

Dennoch können Abweichungen nicht ausgeschlossen werden, sodass wir für die vollständige Übereinstimmung

keine Gewähr übernehmen. Die Angaben in dieser Druckschrift werden regelmäßig überprüft und notwendige

Korrekturen sind in den nachfolgenden Auflagen enthalten.

ASM Assembly Systems GmbH & Co. KG Artikel-Nr.: 00198235-01

Rupert-Mayer-Straße 44

81379 München

Deutschland

www.asm-smt.com

Station Software 710.0 (R16-2) / Version Description 12/2016 Edition

Contents

1 Brief Description 5

2 Scope of Delivery 6

2.1 Software Components ....................................................................................... 6

2.2 Hardware Components ...................................................................................... 6

2.3 Languages ........................................................................................................ 7

3 Compatible Mode 8

4 Features of the 710.0 Station Software Version 9

4.1 SIPLACE TX micron – New Placement Machine ............................................... 9

4.1.1 Vacuum Tooling ................................................................................................ 9

4.1.2 ACT – Dependent on Precision ....................................................................... 10

4.2 Shuttle Extension for SIPLACE TX-Series ....................................................... 10

4.3 Precision Value ............................................................................................... 11

4.4 Alternative Component Shapes ....................................................................... 11

4.5 Odd Shape Components – OSC Package Option ........................................... 12

4.5.1 Vision OSC Measuring Options ....................................................................... 12

4.5.2 Increased Placement Force of Twin VHF ........................................................ 14

4.5.3 Improved Placement of Snap-In Components ................................................. 15

4.5.4 Support to Find Best Acceleration ................................................................... 17

4.6 New Fiducial Type – Notch .............................................................................. 20

4.7 Special Fiducial Evaluation for LED Centering ................................................ 20

4.8 Simplified Tray Teaching for Standard Trays ................................................... 21

4.9 Improved Foil Torn Handling ........................................................................... 21

4.10 Teaching Pickup Location – Nozzle Tip Displayed .......................................... 21

5 Hardware Specifications 22

5.1 Supported Feeder Types .................................................................................

5.2 Camera Systems and Component Ranges ...................................................... 23

6 ASM Software Environment 24

6.1 SIPLACE Pro Programming System Version 14.0 ........................................... 24

6.2 ASM OIS Version 14.0 .................................................................................... 24

6.3 ASM Setup Center Version 9.0 ........................................................................ 24

6.4 ASM Traceability Version 5.2 .......................................................................... 25

7 Restrictions 26

8 Corrected Errors 27

9 Important Terms and Abbreviations 32

10 Licenses 34
