Station Software 710.0 (R16-2) / Version Description 12/2016 Edition

8 Corrected Errors

710.0 Station Software

The 710.0 station software version contains all error corrections of the previous 701.x – 709.x

versions. Additionally, the following errors have been corrected in this version:

Error no. Error description

D1-125536301 Sorting by track did not function in the Vision dumps.

D1-127573107 Table fiducials could not be measured.

D1-128067060 The plate shutter of the BulkFeeder X was open when the machine was

running and the board fully assembled.

D1-128067411 Sporadically, the BulkFeeder X hung up with 38513 Plate or container

shutter: Error

D1-128970072 All four gantries should go to the SPS service position. This failed as a

collision was reported.

D1-129741201 Zero point correction could not be set at the DLM4 star axis.

D1-129804680 Test function Cut could not be repeated.

D1-129883901 Barcode could not be read together with conveyor.

D1-131846701 The station software stopped with an error message during production.

Table 8-1: Corrected errors station software version 710.0

709.1 SP2 Hotfix 1

Error no. Error description

D1-122679801 eSW: SIPLACE SmartFeeder 8mm X: wrong pickup position.

D1-129993001 The cameras were not recognized and BIOS was loaded from the RAM

instead of using the latest version.

D1-130250709 The used component shape seemed to be corrupt (the travel profile was not

correct).

D1-131408001

D1-131824889

eSW: sporadically the mapping data of the Y axis (gantry 2) were not used

respectively there was a problem when the cover was opened and gantry 1

was pushed too close to gantry 2.

D1-131788001 eSW: the download of the embedded software for the TSP420 conveyor did

not work.

D1-131824301 Missing error message in trace files when placement positions were skipped

by the operator.

D1-131877158

D1-133757001

When a waiting time for placement of 250 ms was defined or when a

component should be placed with a high force (>= 30N), the software hung up

with error message:

30016 Unhandled exception error

Station Software 710.0 (R16-2) / Version Description 12/2016 Edition

D1-131921801 If a program with an incomplete component shape and a placement position

that had to be taught was downloaded, the machine started with the teaching

of the placement position even though the component shape had not been

taught.

D1-131949317 After a placement with 70N the machine stopped without error message.

D1-132005405 eSW: error message 30560 Could not detect that the valves on

the valve terminal closed led to a software hang-up.

D1-132028101

D1-131880701

D1-131929707

D1-131985201

D1-132028173

D1-132541001

eSW: the machine stopped with error message 40023 CAUTION: Do not

move gantry! Segment is down.

D1-132146101 eSW: during dry run the machine stopped with error message 40020

Unknown placement state.

D1-132430801 During production, the error 32602 The software has stopped

unexpectedly. Shut down Windows, then restart the station.

occurred.

D1-132508593 Could not calibrate the chuck fiducial position.

D1-132542701 The machine stopped with error message 32590 Possible collisions

with high components

D1-132564701 Although the manual barcode input was deactivated in SIPLACE Pro, it was

still allowed at the station.

D1-132595901 The "single component tracking" for the SWS did not write the board barcode

into the trace file.

D1-132598506 After having opened one cover to change the reel, the machine did not start

again.

D1-132650401 The GUI hung up after a JTG hardware problem.

D1-133060801 Calibrating processing area 2 led to error message 33450 cannot move

calibration plate

D1-133198601 The picture to control the defect position was not displayed when a yellow

board was reported.

D1-133227101 When a component should be picked up by the Twin head, the error message

30341 Position is out of range

occurred.

D1-133265101 Error messages 42416 Move plausibility failure and 42419

Invalid time stamps error

were displayed.

D1-133678341 The board view did not display the placement position anymore.

D17845-11307 The machine could not pick up components from the feeder during normal

production.

D18149-4401

D18149-4501

During production the machine stopped sometimes but the GUI still displayed

production status and no error message.

D18171-10932 Both signal lamps were flashing when there was a track error on one table.

Table 8-2: Corrected errors station software 709.1 SP2 Hotfix 1

Station Software 710.0 (R16-2) / Version Description 12/2016 Edition

709.1 SP2

Error no. Error description

D1-129688701 CA4: the z placement position was 5.55 mm below the chuck / carrier surface.

D1-129846501

D1-129969301

Sudden hang up of station software while board was moving in.

D1-129996049 The calibration of the nozzle changer failed.

D1-130020901 Machines stopped after the download of a recipe with a few changes.

D1-130023381 The Teaching of components GUI and the Vision dump view were not

translated into English and Chinese.

D1-130103401 The setup download was sporadically not accepted.

D1-130157701 eSW: during dry run the machine stopped with error message 40020

Unknown placement state

D1-130240801 Sporadically, the production did not start after the program download.

Table 8-3: Corrected errors station software 709.1 SP2

709.1 SP1

Error no. Error description

D1-114875049 eSW: The machine stopped with different error messages due to CIN box

problems.

D1-125773701 Vision: Ball import did not work correctly.

D1-127133701 Vision: the chuck fiducials could not be measured because a wrong DIPF

description was used.

D1-127531101 eSW: Error message: 32564 Machine has stopped: Cannot set

configuration of conveyor.

D1-127554148

D1-127626412

D1-127643301

D1-127697501

D1-128590353

Vision: The calibration of the Twin or CPP head was stopped with an error

message.

D1-128114565 CLI calculated a wrong number of remaining boards.

D1-128582885 Conveyor control did not fit after recovering conveyor data.

D1-128663401 Vision: The PIN 1 recognition from above did not work. The component could

not be taught.

D1-129343001 eSW: Within the SX1/2 conveyor configuration the extension of the input

conveyor could not be selected.

D1-129342401 The signal lamp status did not change.

D1-129406007 The board was not displayed as yellow board.

D1-129422634

D1-129758101

During production, the error message 32602 The software has

stopped unexpectedly. Shut down Windows, then restart the

station

occurred.
