Station Software 710.0 (R16-2) / Version Description 12/2016 Edition
29
709.1 SP2
Error no. Error description
D1-129688701 CA4: the z placement position was 5.55 mm below the chuck / carrier surface.
D1-129846501
D1-129969301
Sudden hang up of station software while board was moving in.
D1-129996049 The calibration of the nozzle changer failed.
D1-130020901 Machines stopped after the download of a recipe with a few changes.
D1-130023381 The Teaching of components GUI and the Vision dump view were not
translated into English and Chinese.
D1-130103401 The setup download was sporadically not accepted.
D1-130157701 eSW: during dry run the machine stopped with error message 40020
Unknown placement state
.
D1-130240801 Sporadically, the production did not start after the program download.
Table 8-3: Corrected errors station software 709.1 SP2
709.1 SP1
Error no. Error description
D1-114875049 eSW: The machine stopped with different error messages due to CIN box
problems.
D1-125773701 Vision: Ball import did not work correctly.
D1-127133701 Vision: the chuck fiducials could not be measured because a wrong DIPF
description was used.
D1-127531101 eSW: Error message: 32564 Machine has stopped: Cannot set
configuration of conveyor.
D1-127554148
D1-127626412
D1-127643301
D1-127697501
D1-128590353
Vision: The calibration of the Twin or CPP head was stopped with an error
message.
D1-128114565 CLI calculated a wrong number of remaining boards.
D1-128582885 Conveyor control did not fit after recovering conveyor data.
D1-128663401 Vision: The PIN 1 recognition from above did not work. The component could
not be taught.
D1-129343001 eSW: Within the SX1/2 conveyor configuration the extension of the input
conveyor could not be selected.
D1-129342401 The signal lamp status did not change.
D1-129406007 The board was not displayed as yellow board.
D1-129422634
D1-129758101
During production, the error message 32602 The software has
stopped unexpectedly. Shut down Windows, then restart the
station
occurred.
Station Software 710.0 (R16-2) / Version Description 12/2016 Edition
30
D1-129478801 Calibration of head / nozzle changer: the error message that wrong nozzles
are mounted came too soon. It should come after the head selection.
D1-129478898 There was an empty error message when a segment was deactivated during
the overall reference run of the machine.
D1-129506397
D1-129506341
Manual correction of deviation values only took effect on segment 1.
D1-129568901 eSW: Error occurred during offline verification flow.
D1-129683701 eSW: The gantry started to swing during mapping.
D1-129688301 eSW: The x/y axes swang up when the pickup or placement positions were
taught.
D1-129712103 It was not possible to go to the board fiducials (LBO board).
D1-129766401 If auto recovery was active, the error message 32539 Beware of
collision with high components
occurred.
D17710-10001 Vision: Sporadical placement shift caused by the placement position teaching
with gantry 2 and 4 in I-placement mode.
D18149-2501 The C&P20 P head reported 34441 The component sensor has
detected that a component is too thin after pickup
Table 8-4: Corrected errors station software 709.1 SP1
709.1 Hotfix 3
Error no. Error description
D1-125397801 The machine stopped during fiducial measuring.
D1-127315956 The The application has to be closed error message was displayed
on the GUI.
D1-127418201 eSW: Head verification: the z axis did not reach the required value.
D1-127731201 eSW: Sporadically, there were shifted components when they were placed
with low force.
D1-127741201 There was an error when the WPC6 was filled up.
D1-128083301 eSW: error message 31005 Cannot download data to the
subsystem
for all heads.
D1-128124943
D1-128090701
Error message: 30016 Unhandled exception error.
D1-128149593 The Component sensor coated error was triggered during endurance run
on gantry 2.
D1-128150232
D1-128088234
D1-128585501
D1-128140952
eSW: during dry run the machine stopped with the 40020 Unknown
placement state error message.
D1-128188101 The machine did not stop after an SWS error.
D1-128290801 2 nozzles could not be picked up from the nozzle changer after having
returned them manually.
Station Software 710.0 (R16-2) / Version Description 12/2016 Edition
31
D1-128580401 eSW: Error message 30450 Unspecified hardware error for CPP
head.
D1-128590301 eSW: Subsystem was not activated and bottom light barrier was not working.
D1-128638301 LC JobId (Order number) did not appear in Trace data.
D1-128674101 eSW: DPs could not be referenced.
D1-129330401 Error message 30455 The operating system of the processor
has a fatal error
(x axis).
D1-129418601 TX2 with CPP head: a dirty nozzle led to an endless nozzle scan.
Table 8-5: Corrected errors station software 709.1 Hotfix 3
709.1 Hotfix 1
Error no. Error description
D1-124980401
D1-125580001
D1-125592301
During placement, the 32608 StartStopClient_Gantry_1_R.HS:
Waiting until stopped error message appeared.
D1-127059901 When a PCB was removed manually from input side (when the PCB barcode
could not be read) while another PCB was transported to PA2, the machine
stopped without any error message.
D1-127115701 The label feeder was automatically removed from setup after a pickup error.
D1-127219609
D1-125810001
Sporadically, when the cover was open and help was selected, the software
hung up.
D17806-2401 Sporadically, there was a placement offset when the cover was opened.
D17987-3405 There was no error message when the 3D camera was disconnected from the
GCU.
Table 8-6: Corrected errors station software 709.1 Hotfix 1
