Station Software 710.0 (R16-2) / Version Description 12/2016 Edition
31
D1-128580401 eSW: Error message 30450 Unspecified hardware error for CPP
head.
D1-128590301 eSW: Subsystem was not activated and bottom light barrier was not working.
D1-128638301 LC JobId (Order number) did not appear in Trace data.
D1-128674101 eSW: DPs could not be referenced.
D1-129330401 Error message 30455 The operating system of the processor
has a fatal error
(x axis).
D1-129418601 TX2 with CPP head: a dirty nozzle led to an endless nozzle scan.
Table 8-5: Corrected errors station software 709.1 Hotfix 3
709.1 Hotfix 1
Error no. Error description
D1-124980401
D1-125580001
D1-125592301
During placement, the 32608 StartStopClient_Gantry_1_R.HS:
Waiting until stopped error message appeared.
D1-127059901 When a PCB was removed manually from input side (when the PCB barcode
could not be read) while another PCB was transported to PA2, the machine
stopped without any error message.
D1-127115701 The label feeder was automatically removed from setup after a pickup error.
D1-127219609
D1-125810001
Sporadically, when the cover was open and help was selected, the software
hung up.
D17806-2401 Sporadically, there was a placement offset when the cover was opened.
D17987-3405 There was no error message when the 3D camera was disconnected from the
GCU.
Table 8-6: Corrected errors station software 709.1 Hotfix 1
Station Software 710.0 (R16-2) / Version Description 12/2016 Edition
32
9 Important Terms and Abbreviations
CA4 Machine type of the Chip Assembly (CA)-series with 4 gantries
and 2 PAs
C&P Collect & Place
CPP Collect & Place & Pick & Place
DC Dual Conveyor
DX1/DX2 Machine type with 1 or 2 gantries and 1 PA
EDIF Electronic Design Interchange Format
eWLP embedded Wafer Level Process
FCCS Field Camera Calibration System
GUI Graphical User Interface
HFH High Force Head
HW Hardware
MGCU Modular Gantry Control Unit
MHCU Modular Head Control Unit
MTC Matrix Tray Changer
OIS Operator Information System
PA Processing area
PCB Printed circuit board
Placement mode:
2-in-1
When a machine runs in I-Placement mode it is possible to
perform manual operations for one side / gantry.This placement
mode is also called "independent".
Placement mode:
Alternating
Placement mode in a dual gantry placement area, in which both
gantries place components on both boards in a dual conveyor.
First, both gantries place all assigned components on the board
in lane one and then on the board in lane two.
Placement mode:
Borrow
Performance
A line runs in I-Placement mode and to get a balanced
throughput between the left and right conveyor lanes, e.g. the
last machine runs in Alternating mode and places components in
this placement area on the board of the other lane.
Placement mode:
I-Placement
Placement mode in a dual gantry placement area in which each
gantry only places components on the board of the assigned
conveyor lane.
SC Single Conveyor
SC SIPLACE Setup Center (external setup control system)
SW Software
SWS SIPLACE Wafer System
SX1/SX2 Machine type with 1 or 2 gantries and 1 PA
TH Twin Head
TH HF Twin Head High Force
Twin VHF Very High Force Twin Head
Station Software 710.0 (R16-2) / Version Description 12/2016 Edition
33
TX1/TX2/TX2i Machine type with 1 or 2 gantries and 1 PA
TX2 micron/
TX2i micron
Machine type with 2 gantries and 1 PA
VC Vision computer
VCU Vision Control Unit
VHF P&P Very High Force Pick&Place
WLFO Wafer Level Fan-Out, Chip Assembly process
WPC Waffle Pack Changer
X2/X2 S Machine type with 2 gantries and 2 PAs
X3/X3 S Machine types with 3 gantries and 2 PAs
X4/X4 S/
X4 S micron
Machine types with 4 gantries and 2 PAs
X4i/X4i S
X4i S micron
Machine types with 4 gantries and 2 PAs
