GEM Manual for DEK Printers Equipment Variables
Issue 2.0 June 9th, 2011 page 111 of 156
7.4 Discrete Data Variables
The discrete data variables are defined in the table below:
Name DVID
Limits
Monitor
Description Type Value Range
GemAlarmId 2001 No Identity of alarm transition. U4 See chapter 6.
pp_old_file_name 2002 No Name of process program being
changed.
A8
Any characters valid in a DOS
filename.
pp_change_status 2003 No Type of process program change. U1 1 = Load process program
2 = Rename process program
3 = Erase process program
measured_cycle_time 2004 Yes The duration in seconds of the most
recent machine cycle.
F8 0 = no data
to 3.2 million seconds
throughput_cycle_time 2005 Yes The average duration in seconds of
the machine cycle time. Averaged
over the last 1 to 50 cycles.
F8 0 = no data
to 3.2 million seconds
Reserved 2006 No
ecid_changed 2007 No VID of changed equipment
constant.
U4
front_print_pressure 2008 Yes Front squeegee pressure of last
cycle.
F8 0-20 Kg
rear_print_pressure 2009 Yes Rear squeegee pressure of last
cycle.
F8 0-20 Kg
print_speed 2010 Yes
Speed measured during the last print
stroke.
F8 2-150 mm/s
table_separation_speed 2011 Yes Speed of board and screen
separation measured during last
print cycle.
F8 0.1-20 mm/s
board_stretch_error 2012 Yes Difference between board and
screen fiducials measured after the
print cycle.
F8
±5.0 mm
Xerr 2013 Yes X alignment accuracy. F8
±0.025 mm
Yerr 2014 Yes Y alignment accuracy. F8
±0.025 mm
theta_err 2015 Yes Theta alignment accuracy. F8 arcsec
Squeegee 2016 No Squeegee used to perform the last
print.
U1 0 = No action.
1 = Front squeegee.
2 = Rear squeegee.
current_screen_bar_code 2017 No The barcode of
the current screen as
scanned when the screen was
loaded.
The default is “NO CODE”.
A32 Up to a 32 character string.
The actual length is
determined by the barcode.
old_time 2018 No The previous value of the clock
before it was last changed.
A12
A16
Yymmddhhmmss
Yyyymmddhhmmsscc
new_time 2019 No The time that the clock was last
changed.
A12/
A16
Yymmddhhmmss
Yyyymmddhhmmsscc
product_bar_code 2020 No
The most recent barcode scanned by
the product barcode reader. The
default is “NO CODE”.
A32 Up to a 32 character string.
The actual length is
determined by the barcode.
board_fiducial_1_score 2021 Yes The acceptance score of board
fiducial 1.
U4 0-1000
board_fiducial_2_score 2022 Yes The acceptance score of board
fiducial 2.
U4 0-1000
board_fiducial_3_score 2023 Yes The acceptance score of board
fiducial 3.
3 fiducial mode must be selected.
U4 0-1000
screen_fiducial_1_score 2024 Yes The acceptance score of screen
fiducial 1.
U4 0-1000
GEM Manual for DEK Printers Equipment Variables
Issue 2.0 June 9th, 2011 page 112 of 156
Name DVID
Limits
Monitor
Description Type Value Range
screen_fiducial_2_score 2025 Yes The acceptance score of screen
fiducial 2.
U4 0-1000
screen_fiducial_3_score 2026 Yes The acceptance score of screen
fiducial 3.
3 fiducial mode must be selected.
U4 0-1000
LimitVariable 2027 No This variable contains the VID for
the variable whose value changed
monitoring zones.
U4 See list of VID’s for limits
monitoring.
EventLimit 2028 No This variable contains the LIMITID
of the limit reached or crossed by
LimitVariable. Since multiple zone
transitions for a variable may occur
simultaneously, EventLimit has
been defined to allow for a list of
LIMITIDs.
List of
U1
1-7
TransitionType 2029 No This variable defines the direction
of the zone transition that has
occurred.
B
1 byte
0 = Transition from lower
zone to upper zone.
1 = Transition from upper
zone to lower zone.
RemoteBarCode 2030 No Product bar code string provided by
the serial bar code reader.
The default is “NO CODE”.
A32 Up to a 32 character string.
The actual length is
determined by the barcode.
ProflowPastePressure 2031 Yes Actual Paste Pressure used by the
Proflow paste mechanism.
F8 0-20 Kg
Reserved 2032 No Not used by the 265.
Traceability Data 2033 No List of traceability data for the last
processed product.
Variabl
e
See <Traceability Data>
Failed verification item 2034 No List of the items that last failed
verification
Variabl
e
See <Failed Verification
Items>
Reserved 2083 No
Reserved 2084 No
Reserved 2085 No Not used.
front_print_speed 2086 Yes
Speed measured during the last front
print stroke.
F8 2-150 mm/s
rear_print_speed 2087 Yes Speed measured during the last rear
print stroke.
F8 2-150 mm/s
Modified Parameters 2088 No
This variable contains the parameter
ID, name, old value and new value
for the parameters whose value
changed at instrument.
Modifi
ed
Parame
ter List
See <Modified Parameter
List>
GEM Manual for DEK Printers Equipment Variables
Issue 2.0 June 9th, 2011 page 113 of 156
7.4.1 Limit List
The Limit Set Values are held in a list that is structured as follows:
<Limit List>
:
Structure: L, m ; m = Number of Limit sets
; with SPC output enabled.
1. L, 28 ; First Limit Set
1. Limit Blockage Ave ;Type F4
2. Limit Blockage Max ;Type F4
3. Limit blockage Max Site ID ;Type A20
4. Limit Blockage Min ;Type F4
5. Limit blockage Max Site ID ;Type A20
6. Limit Paste Ave ;Type F4
7. Limit Paste Max ;Type F4
8. Limit paste Max Site ID ;Type A20
9. Limit Paste Min ;Type F4
10. Limit paste Min Site ID ;Type A20
11. Limit Volume Ave ;Type F4
12. Limit Volume Max ;Type F4
13. Limit volume Max Site ID ;Type A20
14. Limit Volume Min ;Type F4
15. Limit volume Min Site ID ;Type A20
16. Limit Print X Ave ;Type F8
17. Limit Print X Max ;Type F8
18. Limit print X Max Site ID ;Type A20
19. Limit Print X Min ;Type F8
20. Limit print X Min Site ID ;Type A20
21. Limit Print Y Ave ;Type F8
22. Limit Print Y Max ;Type F8
23. Limit print Y Max Site ID ;Type A20
24. Limit Print Y Min ;Type F8
25. Limit print Y Min Site ID ;Type A20
26. Limit Smear ;Type F8
27. Limit Bridging ;Type F8
28. Limit ID ;Type A20
.
. ; all elements of the list are identically
m. ; structured
