GEM Manual for DEK Printers Capabilities

Issue 2.0 June 9th, 2011 page 26 of 156

Scenario:

Collection event report set up and send:

Comments Host Equipment Comments

[IF] Define report is multi-block

[THEN] Send multi-block inquire

S2F39 -->

[END_IF] <-- S2F40 Multi-block grant

Send report definition S2F33 --> Receive DATAID’s, RPTID’s, & VID’s

<-- S2F34 Send DRACK = 0 report is OK

[IF]Link event report is multi-block

[THEN] Send multi-block inquire

S2F39 -->

[END_IF] <-- S2F40 Multi-block grant

Link reports to events S2F35 --> CEID's & RPTID's received

<-- S2F36 LRACK = 0

Enable specific collection events S2F37 --> CEED's & CEID's received

<-- S2F38 ERACK = 0

CEID, RPTID's & values received <-- S6F11 Some time later, an event occurs

Acknowledge report S6F12 -->

5.2.2 Variable Data Collection

This capability facilitates synchronisation and initialisation. It enables the host to

request equipment data variables, but should not be used for discrete data.

The host can request any, previously defined, RPTID (see 3.2.1). The equipment sends

current values for Status variables (SV's) and Equipment Constants (ECV's). Discrete

variables (DVVAL's) are not valid.

Scenario:

Collection event report set up and send:

Comments Host Equipment Comments

Host requests data variables S6F19 -->

<-- S6F20 Equipment responds with list of variable data

for given RPTID

GEM Manual for DEK Printers Capabilities

Issue 2.0 June 9th, 2011 page 27 of 156

5.2.3 Trace Data Collection

This capability enables reports to be sent at fixed intervals. This is achieved as follows:

The host initialises a trace by sending S2F23. This message defines the trace

report including, time interval (DSPER), total number of samples (TOTSMP),

the number of samples per trace report (REPGSZ) and a list of data to report

(SVID's). The host also provides an identity for the trace (TRID) so that it can

later differentiate between simultaneous traces.

The total number of reports sent will be TOTSMP/ REPGSZ unless the host

sends a new S2F13 with the same TRID, when the trace replaced by a new one.

The host can end a trace by sending the same TRID, with TOTSMP = 0.

For a detailed example, of trace data collection, refer to note A.4 of SEMI E30 standard.

Scenario:

Collection event report set up and send:

Comments Host Equipment Comments

Trace Data Initialisation Request S2F23 -->

<-- S2F24 Acknowledge trace init.

[DO] TOTSMP / REPGSZ times

[DO] REPGSZ times: collect

SVID1-SVIDn data, wait DSPER

[END_DO]

<-- S6F1 Send report.

Acknowledge report S6F2 -->

Optional terminate. TOTSMP = 0 S2F23 -->

<-- S2F24 Acknowledge premature terminate. Stop trace.

[END_DO]

GEM Manual for DEK Printers Capabilities

Issue 2.0 June 9th, 2011 page 28 of 156

5.2.4 Status Data Collection

The host can use this capability to request selected status information. It provides for

synchronisation of equipment status.

To obtain a status report, the host sends a request with a list of specific SVID's. The

equipment will respond with a list of status values.

Scenarios:

Equipment status variable report request:

Comments Host Equipment Comments

Host requests report of selected status

values.

S1F3 -->

<-- S1F4 Equipment replies with requested data

Equipment status variable namelist request:

Comments Host Equipment Comments

Host requests equipment to identify

selected status values.

S1F11 -->

<-- S1F12 Equipment replies with requested status variable

descriptions.

5.2.5 On-Line Identification

Using this capability, the host can confirm the presence of the equipment. The

equipment will send its identity MDLN and software revision SOFTREV in response to
