GEM Manual for DEK Printers Equipment Variables
Issue 2.0 June 9th, 2011 page 121 of 156
Name OBJID
PRINT REAR LIMIT 74
DRY CLEAN SPEED 83
WET CLEAN SPEED 84
VAC CLEAN SPEED 85
FRONT START OFFSET 86
REAR START OFFSET 87
SEPARATION DELAY 89
PRINT AREA WIDTH 100
PASTE WITH BOARD 104
PRINT AREA LENGTH 105
DIST TO IMAGE 110
PRINT PASTE PRESSURE 115
IDLE PASTE PRESSURE 116
CUSTOM SCREEN 120
PASTE RIDGE REMOVAL 185
SEPARATE VAC DELAY 187
FLATTEN VAC DELAY 188
REAR PRINT SPEED 199
VORTEX SOLVENT RATE 223
VACUUM ON PERIOD 224
VORTEX VACUUM RATE 225
VORTEX VAC START 226
VORTEX VAC STOP 227
VORTEX CLEAN RATE 228
VORTEX CASSETTE LIFE 229
FRONT KNEAD PRESSURE 245
REAR KNEAD PRESSURE 246
FRONT KNEAD SPEED 247
REAR KNEAD SPEED 248
SELECT MARK TYPE 252
SELECT MARK X 267
SELECT MARK Y 268
FRONT PASTE RECOVERY 273
REAR PASTE RECOVERY 274
PASTE RECOVERY RATE 275
KNEAD BEFORE PRINT 276
KNEAD OFF 277
STENCIL PROTECTION 278
SYSTEM PRESSURE 280
TOOLING DEVIATION 284
SINGULATION 342
PALLET THICKNESS 346
FIRST PART TO EDGE 348
PITCH OF PARTS 349
PALLET WIDTH 350
PALLET LENGTH 351
NUMBER OF PARTS 352
VAC CLEAN START TIME 387
BOARD AT STOP RUN ON 399
KNEAD PASTE PRESSURE 428
KNEAD AFTER REPLENISH 429
CLEAN AFTER KNEAD 430
Name OBJID
RWD END PRESSURE 431
RWD START PRESSURE 432
FWD END PRESSURE 433
FWD START PRESSURE 434
RWD END SPEED 435
RWD START SPEED 436
FWD END SPEED 437
FWD START SPEED 438
VACUUM SENSOR DELAY 451
FLOOD SPEED 452
REAR KNEAD SPEED 453
FRONT KNEAD SPEED 454
REAR PRINT SPEED 455
FRONT PRINT SPEED 456
FWD END SPEED 457
FWD START SPEED 458
RWD START SPEED 459
RWD END SPEED 460
LOADING FRAME REAR 571
SELECTIVE PRINT 625
SELECTIVE PRINT OK 626
SELECTIVE PRINT FAIL 627
SOFT RAIL LIFT/LAND 628
SOFT LIFT/LAND SPEED 629
SOFT LIFT/LAND DIST 630
VIEW ROUGH ALIGNMENT 692
VORTEX CLEAN STROKES 698
TOOLING TYPE 750
CLEAN AFTER DOWNTIME 784
CLEAN AFTER KNEAD 785
CLEAN AFTER KNEAD 788
ADVANCE AT RUN 870
ADVANCE AFTER WET 871
ADVANCE BEFORE WET 872
ADVANCE BEFORE VAC 873
ADVANCE BEFORE DRY 874
STEP ADVANCE 998
RIGHT FEED DELAY 1000
WET CLEAN SPEED 1034
VAC CLEAN SPEED 1035
DRY CLEAN SPEED 1036
SCREEN CLEAN MODE 1 1037
SCREEN CLEAN MODE 2 1038
CLEAN AFTER KNEAD 1039
CLEAN AFTER DOWNTIME 1040
GERBER FILENAME 1113
Start Modification >>>
SOLVENT DISPENSE 1242
PAPER ADVANCE 1243
<<< End Modification
TRANSFER HEAD SIZE 5231
REMOTE BOARD STOP X 6462
GEM Manual for DEK Printers Equipment Variables
Issue 2.0 June 9th, 2011 page 122 of 156
Name OBJID
CLEAN AFTER DOWNTIME 6550
CLEAN AFTER 6555
PRODUCT ID 10000
SEPARATION DISTANCE 10005
PRINT VACUUM MODE 10031
DWELL SPEED 10060
DWELL HEIGHT 10061
BOARD 1 FID TYPE 11000
SCREEN 1 FID TYPE 11100
BOARD 2 FID TYPE 11200
Name OBJID
SCREEN 2 FID TYPE 11300
BOARD 3 FID TYPE 11400
SCREEN 3 FID TYPE 11500
2D INSPECT RATE 12027
APPROACH SPEED 30018
APPROACH DISTANCE 30019
TABLE DOWN SPEED 30020
SPHERE RECOVER SPEED 30021
SPHERE RECOVER DIST 30022
HOPPER OPEN PRESSURE 30023
GEM Manual for DEK Printers Alarms
Issue 2.0 June 9th, 2011 page 123 of 156
8 Alarms
Safety Alarms 8.1
System Alarms 8.2
Hardware Alarms 8.3
Board Transport Alarms 8.4
Process Alarms 8.5
Consumable Alarms 8.6
