Software Version Description, Station Software Version 407.05 07/2008 Edition

SIPLACE S20

File Variable Description / Restriction

KRAFT_12.MA Axis block 1:

In addition, 1 active value ID: 19

All force levels: 6th value, old 2047, new 80

Force level 13 (higher than 8x noz.): 2nd value, old 80, new 40

Force level 13 (higher than 8x noz.): 3rd value, old 18, new 0

Force level 13 (higher than 8x noz.): 4th and 5th value, old 250,

new 150

Force level 13 (higher than 8x noz.): 6th value, old 2047, new

Changed values for pick-up with

nozzles in 8-nozzle heads

PPW_STD.MA \ D-Sollposition \ jeweils 0 Nozzles wiped off at 0 degrees

(00601)

REAL.MA Backlash times changed (00603)

SCANPA12.MA New parameter values (00614)

TRANSP.MA Center conveyor coasting and PCB

timeout configurable (00604)

ref_lauf.ma Default entry for adjustable retries

for the error: track empty (605)

SIPLACE S23

File Variable Description / Restriction

PPW_STD.MA \ D-Sollposition \ jeweils 0 Nozzles wiped off at 0 degrees

(00601)

REAL.MA Backlash times changed (00603)

SCANPA12.MA New parameter values (00614)

TRANSP.MA Center conveyor coasting and PCB

timeout configurable (00604)

ref_lauf.ma Default entry for adjustable retries

for the error: track empty (605)

32 of 104

Software Version Description, Station Software Version 407.05 07/2008 Edition

5.8 New Functions in 407.01

Version 407.01 of the software is based on Version 406.01 and incorporates all the functions and bugfixes of

this version. Version 407.01 of the software also incorporates the following new features and changes:

• Improved fiducial and ink spot recognition

• Clusters without fiducials

• Position recognition before ink spot recognition

• Component level indicator function (option)

• Feeder position recognition

• Version check

• New "multicolor" PCB camera for F5HM

• 88 mm tape feeder

• Vacuum evaluation

• Top / bottom PCB barcode

5.8.1 Improved Fiducial and Ink Spot Recognition

There are three additional views in the fiducial manipulator (Synthetic fiducial, Ink spot and Illumination). This

makes it possible to teach in synthetic fiducials and ink spots. A fiducial can either be taught as an ink spot,

a taught fiducial or a synthetic fiducial. It is only possible to change the type using New fiducial, thereby

deleting the fiducial content. Synthetic fiducials increase the stability of fiducial recognition. Geometry and

tolerance are entered for synthetic fiducials.

The new ink spots increase the reliability and above all the speed of ink spot measurement. The teach-in

procedure for ink spots uses a wizard. "Go" and "No Go" detection takes place at the same high speed. An

illumination dialog is provided for the new PCB camera.

The new fiducial process supports circles, squares, rhombuses, rectangles, hollow circles, hollow rectangles

and crosses. The double cross is not supported. This can only be used with the old fiducial procedure. Circle

and square fiducials are particularly well suited in terms of accuracy and speed. The cross is equivalent in

terms of accuracy, although its finer structures mean it takes longer. The rhombus can be used if structures

such as vias and pads which may interfere with the fiducial are in the vicinity. No practical experience is

currently available with the rhombus.

Important:

• Although hollow circles and hollow rectangles are supported, we would not advise applying these

fiducials to new designs. This is because these geometries are less well suited to reliable evaluation and

do not result in an increase in accuracy.

• In the context of teaching synthetic fiducials and ink spots the option "automatic positioning" is available

only for transport 1.

33 of 104

Software Version Description, Station Software Version 407.05 07/2008 Edition

5.8.2 Clusters without Fiducials

An error message is output at the station if the host computer sends a cluster to the station but the cluster

does not contain all the required fiducials. The station displays the status for the operator to teach in the

missing fiducials in the fiducial manipulator.

The missing fiducials are displayed in a dialog (separated according to conveyor in the case of a dual

conveyor) when the operator calls up the fiducial manipulator In the fiducial manipulator, it is possible to

move to the fiducial position defined in the cluster.

5.8.3 Position Recognition before Ink Spot Recognition

Two separate methods for measuring fiducials and ink spots are supported as of version 407.01.

This makes it possible to move to ink spots without prior position recognition. In future, the sequence " Ink

spot recognition before position recognition" will be the default. In particular in the case of small ink spots, it

may still be necessary to carry out position recognition before ink spot recognition. When teaching an ink

spot, however, the user has the option of deactivating the Position recognition before ink spot recognition

option, provided that the dimensions of the ink spot do not make it necessary to first carry out position

recognition.

5.8.4 Component Level Indicator

Level monitoring is an option with software version 407.01. It warns the operator in good time that feeder

tracks are approaching empty, so that there is enough time to refill them (splicing component tapes).

- Level monitoring is activated using a separate Installation - CD.

- Level monitoring can be selected using the Set-up view.

- For each feeder, a list displays the current stock of components, the remaining buffer time, the

component name, location, track, division and the status (active/inactive).

- The number of accesses is counted for each feeder. Following placement of components on a printed

circuit board, the component levels in the feeders are updated in the view.

- A track error warns the operator if the component levels or buffer times are less than adjustable

threshold values. Alternatively, the affected tracks are set to empty.

- The signal that the values are less than the threshold is issued using the signal lamp, a colored marking

in the Component level indicator view and by error messages.

- The tracks are identified using colors according to their status in the Component level indicator view:

Green: Sufficient components are available

Yellow: Component supply will soon be exhausted

Red: Track is set to empty due to the low component stock. Nothing more is collected from this track

until it is refilled.

- The operator can use the line computer (or local control) to specify the container sizes for the individual

feeders. The operator can use the station computer interface to activate/deactivate tracks, alter

component levels, set threshold values and alter the sorting sequence used in the list.
