Software Version Description, Station Software Version 407.05 07/2008 Edition 9.3 Inst allation of the SIPLACE Software 9.3.1 Interfaces To be able to install the optional GEM application software on the GEM computer, th…
Software Version Description, Station Software Version 407.05 07/2008 Edition
Setup Page Parameter Value
7 Not assigned transparent
10 SMP_INT5 transparent
11 SMP_INT6 transparent
14 Onboard IDE transparent
PCI Setup MultiMedia Enable disabled
INT A
7
INT B none
INT C none
INT D none
COM Redirection Status enabled (ANSI/VT100)
Baudrate 19200 Bd
Mode Autoredirection
IMC Miscellaneous Disable CTRL-C/CTRL-BREAK disabled
Force Cold boot on CTRL-ALT-DEL disabled
Disable BIOS E-Segment at boot
enabled
9.2.2.2 Installation
The installation of the machine controller operating system for the SIPLACE S23 / F5HM is identical to that
for other machine types. Copies of the diskettes are contained on the station software CD in the directory
Siplace\Sip_mc\80s23\FD_image.RM3. The diskettes can be created on any PC running under Windows-
NT, e.g. the station computer. To this end, start the programs rmos-1.exe, or rmos-2.exe and follow the
directions. Be sure to use the correct set of diskettes (for SIPLACE S23 / F5HM) as otherwise the operating
system will not run up properly although the installation was performed successfully.
76 of 104
Software Version Description, Station Software Version 407.05 07/2008 Edition
9.3 Installation of the SIPLACE Software
9.3.1 Interfaces
To be able to install the optional GEM application software on the GEM computer, the Windows for GEM
software version V407.02 must be installed.
9.3.2 Installation Instructions/Upgrade Instructions
9.3.2.1 Definitions
9.3.2.1.1 Initial Installation
The first-time installation of the Station Software on the SIPLACE machines S-20 and F
4
is referred to as
"initial installation".
9.3.2.1.2 Update
If an initial installation was previously performed and a new revision level of the Station Software is to be
loaded, this procedure is referred to as an "Update". The revision level is identified by the last two numerals
of the complete version number.
9.3.2.1.3 Upgrade
The functionality of the station software is identified by the three-digit code integrated in the complete version
number.
Example:
407.xx = The number 407 indicates the functionality of the software
The installation of a SW version with a higher version number than the already-installed SW version is
referred to as an "Upgrade".
9.3.2.2 Installation of the Station Computer and the Machine Controller
The installation time depends on the machine type to be installed. It takes 30 minutes on average for the
SIPLACE S20, SIPLACE F
4
, SIPLACE F
5
and about 15 minutes for the SIPLACE S23 and SIPLACE F5HM
systems.
There are only two differences between installing station software for Windows XP and the familiar
installation under Windows NT. Explicit reference is made to these differences at the relevant points.
77 of 104
Software Version Description, Station Software Version 407.05 07/2008 Edition
9.3.2.3 Installation Program
• Turn on the station.
• When the Windows screen appears, keep the Shift key depressed to prevent the system from booting
automatically.
• Log in as an administrator!
• Once you have inserted the CD into the CD-ROM drive, the installation will start with the language
selection.
Language Selection
In the first screen a query is displayed asking you in which language the installation program is to
communicate with you. You can select between German and English.
Fig: Language Selection
Choose OK to reach the welcome screen.
78 of 104
