Software Version Description, Station Software Version 407.05 07/2008 Edition  Setup page "Boot Features" +----------------------¦ Boot Features +-----------------------+ ¦ ¦ ¦ +------+ +------+ +-------+ ¦ ¦ …

Software Version Description, Station Software Version 407.05 07/2008 Edition

Primary IDE Controller

For the first IDE channel, the following parameters have to be defined.

Auto If this option is activated, BIOS will attempt - upon start-up - to detect the

parameters of the hard disk and to set them up optimally.

Be sure to never execute this option, as otherwise the values for

Cyl/Heads/SPT have to be re-entered.

Type The hard disk type is always USR1

Cyl

Number of cylinders of the hard disk (always 4096)

Heads

Number of heads of the hard disk (always 16)

SPT

Number of sectors per track (always 63)

Precomp Write Precompensation

L-Zone

Landing zone (always 4199)

Size The size of the hard disk in MB will be calculated automatically by the BIOS

based on the parameters and cannot be set.

Trans Mode Transfer mode of hard disk

Normal

For hard disks larger than 504 MB, Normal Mode has to be used under

RMOS.

Important:

None of the options Block Mode, 32 bit or Fast PIO must be activated !

70 of 104

Software Version Description, Station Software Version 407.05 07/2008 Edition

 Setup page "Boot Features"

+----------------------¦ Boot Features +-----------------------+

¦ ¦

¦ +------+ +------+ +-------+ ¦

¦ Press [F1] key for help ¦ OK ¦ ¦Cancel¦ ¦Default¦ ¦

¦ +------+ +------+ +-------+ ¦

¦ +-Boot Sequence---------+ +-Keyboard State-----------------+ ¦

¦ ¦ ¦ ¦ [ ] Typematic Settings Enabled ¦ ¦

¦ ¦ (*) A:, C: ¦ ¦ Typematic Rate: 6 (char/s) ¦ ¦

¦ ¦ ( ) C:, A: ¦ ¦ Typematic Delay: 250 (msec) ¦ ¦

¦ ¦ ¦ ¦ [v] Num Lock On ¦ ¦

¦ +-----------------------+ +--------------------------------+ ¦

¦ +-Halt On Errors--------+ +-System Memory------------------+ ¦

¦ ¦ [v] Halt on Errors ¦ ¦ ¦ ¦

¦ ¦ Except for ... ¦ ¦ [ ] Quick Memory Test ¦ ¦

¦ ¦ [ ] Keyboard Errors ¦ ¦ ¦ ¦

¦ ¦ [ ] Disk Errors ¦ ¦ ¦ ¦

¦ +-----------------------+ +--------------------------------+ ¦

¦ Press [F1] key for help ¦

+--------------------------------------------------------------+

 Setup page "Standard Chipset"

+--------------------¦ Standard Chipset +---------------------+

¦ ¦

¦ +------+ +------+ +-------+ ¦

¦ ¦ OK ¦ ¦Cancel¦ ¦Default¦ ¦

¦ +-System Cache-------------+ +------+ +------+ +-------+ ¦

¦ ¦ ( ) Disabled ¦ ¦

¦ ¦ ( ) Primary Only ¦ +-Secondary Cache Size-------+ ¦

¦ ¦ (*) Primary and Secondary¦ ¦ 256 KB Pipelined Burst ¦ ¦

¦ +--------------------------+ +----------------------------+ ¦

¦ +-Shadow and Cache Options--------------------------------+ ¦

¦ ¦ Shadow Cache Shadow Cache ¦ ¦

¦ ¦ System ROM: [v] Video ROM: [v] [v] ¦ ¦

¦ ¦ C800-CBFF: [ ] [ ] CC00-CFFF: [ ] [ ] ¦ ¦

¦ ¦ D000-D3FF: [ ] [ ] D400-D7FF: [ ] [ ] ¦ ¦

¦ ¦ D800-DBFF: [ ] [ ] DC00-DFFF: [ ] [ ] ¦ ¦

¦ +---------------------------------------------------------+ ¦

¦ Press [F1] key for help ¦

+-------------------------------------------------------------+

71 of 104

Software Version Description, Station Software Version 407.05 07/2008 Edition

 Setup page "Advanced Chipset"

+---------------------------¦ Advanced Chipset +----------------------------+

¦+-DRAM Timing-----------------------++-DRAM Error--------++--------------+ ¦

¦¦ ¦¦ ¦¦ +------+ ¦ ¦

¦¦ DRAM Speed: (*) 60 ns ¦¦ ¦¦ ¦ OK ¦ ¦ ¦

¦¦ ( ) 70 ns ¦¦ (*) None ¦¦ +------+ ¦ ¦

¦¦ ( ) User defined ¦¦ ( ) Parity ¦¦ +------+ ¦ ¦

¦¦ ¦¦ ( ) ECC ¦¦ ¦Cancel¦ ¦ ¦

¦¦ DRAM Read Burst: x222/x333 ¦¦ ¦¦ +------+ ¦ ¦

¦¦ DRAM Write Burst: x222 ¦¦ (*) Multiple ¦¦ ¦ ¦

¦¦ Fast RAS to CAS Delay: 3 Clocks ¦¦ ( ) Single ¦¦ +-------+ ¦ ¦

¦¦ Leadoff: 6 Cl-Rd, 5 Cl-Wr, 3 RAS ¦¦ ¦¦ ¦Default¦ ¦ ¦

¦¦ ¦¦ ¦¦ +-------+ ¦ ¦

¦+-----------------------------------++-------------------++--------------+ ¦

¦+-I/O Recovery Times----------------++-Miscellaneous---------------------+ ¦

¦¦ ¦¦ ¦ ¦

¦¦ 8 Bit Cycles: +1 Clock ¦¦ [v] Enable Memory Hole at 15-16MB ¦ ¦

¦¦ 16 Bit Cycles: +1 Clock ¦¦ ¦ ¦

¦¦ ¦¦ ¦ ¦

¦+-----------------------------------++-----------------------------------+ ¦

¦ Press [F1] key for help ¦

+---------------------------------------------------------------------------+

Miscellaneous

Enable Memory Hole

at 15-16MB

Address window for SIPLACE GEM option

 Setup page "Peripherals"

+------------------------¦ Peripherals +------------------------+

¦ ¦

¦ +-Serial / Parallel Ports-----------------------+ ¦

¦ ¦ Serial Port A: 3F8h, IRQ4 ¦ +------+ ¦

¦ ¦ Serial Port B: 2F8h, IRQ3 ¦ ¦ OK ¦ ¦

¦ ¦ Parallel Port: 378h, IRQ7 Bidirectional ¦ +------+ ¦

¦ +-----------------------------------------------+ ¦

¦ +-IDE / Floppy Controller-----------------------+ +------+ ¦

¦ ¦ Primary IDE: Enabled ¦ ¦Cancel¦ ¦

¦ ¦ Secondary IDE: Disabled ¦ +------+ ¦

¦ ¦ Floppy Disks: Enabled Normal ¦ ¦

¦ +-----------------------------------------------+ +-------+ ¦

¦ +-Miscellaneous---------------------------------+ ¦Default¦ ¦

¦ ¦ PS/2 Mouse: Enabled ¦ +-------+ ¦

¦ +-----------------------------------------------+ ¦

¦ Press [F1] key for help ¦

+---------------------------------------------------------------+
