Installation Manual, Windows XP Embedded operating system for the machine controller Issue 04/2007
3.1 Upgrade packages and components for upgrading from Version 603.x
Caution:
For upgrading to the software version 604.x on the SIMATIC BoxPC 627, please consider the
installation manual in hand “Windows Embedded XP operating system for the MC German and
English”.
It is not necessary to install the Windows embedded XP operating system for the other
machines.
No further upgrade packages or components are required.
3.2 Upgrade packages and components for upgrading from Version 601.x
or 602.x
Caution:
For upgrading to the software version 604.x, please consider the installation manual in hand
“Windows Embedded XP operating system for the MC German and English”.
The following upgrade packages for SIPLACE X4, X2 and X3 machines with CPU 076 are required:
- Upgrade package for SIPLACE X4 with CPU 076 Æ Computer upgrade to CPU 086
Item number: 03029123S03
- Upgrade package for SIPLACE X2 and X3 with CPU 076 Æ 128 MB memory expansion
Item number: 03051831
8 of 28
Installation Manual, Windows XP Embedded operating system for the machine controller Issue 04/2007
4 Prerequisites for installation
4.1 Software components
- Standard package Software SIPLACE Station as of version 603.01 or later
SC 603.01 (item number: 00383500-xx)
SC 604.01 (item number: 00385500-01)
- Hardware components (see section
4.2)
Caution:
Before installing the operation system on the machine controller, ensure that the network cable is
connected to the station computer and the network connection is working.
9 of 28
Installation Manual, Windows XP Embedded operating system for the machine controller Issue 04/2007
10 of 28
4.2 Hardware components of the computer system for the machine
controller
4.2.1 SIPLACE X series and SIPLACE D3 machine controller hardware
Name SMP16-CPU076
CPU / clock frequency Celeron / 650 MHz
RAM 256 MB
Hard disk 40 GB
External DVD drive No
Floppy drive 3.5", 1.44 MB
USB interfaces
and external USB hub
Yes
Network 1 x 10/100Base-T
Table 4-1: Machine controller hardware (previous configuration of SIPLACE X series)
Name SMP16-CPU086
CPU / clock frequency Intel M / 1600 MHz
RAM 512 MB
Hard disk 40 GB
External DVD drive No
USB interfaces
and external USB hub
Yes
Network 1 x 10/100Base-T
Table 4-2: Machine controller hardware (current configuration of SIPLACE X series and SIPLACE D3)
Name SIMATIC Box PC 627
CPU / clock frequency Pentium M / 2 GHz
RAM 1 GB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces
and external USB hub
Yes
Network 2x 100 MBit
Table 4-3: Machine controller hardware (future configuration of SIPLACE X series and SIPLACE D3)
