2.3 Composition of Operation Data
The set parameters are used to manage the overall pattern program data.
This data is composed of the PCB data, the PEC recognition data, the PEC
recognition mark data, and the setup data.
Reference
Refer to "3.3 Operation in Chapter 2" for the details of earth item
C01 Function Data
Items Ref. No.
PEC recognition function C01_01
All (Zones 1 through 5) C01_02
Image C01_03
Local C01_04
Zones 1, 2, 3, 4 and 5
#1 X [mm] (Horizontal) and Y [mm] (Vertical)
#1 Mark Code
#2 X [mm] (Horizontal) and Y [mm] (Vertical)
#2 Mark Code
#3 X [mm] (Horizontal) and Y [mm] (Vertical)
#3 Mark Code
C01_05
T2B4
C02 PEC Recognition Mark Data
Items Ref. No.
Mark No. C02_01
Mark Type C02_02
Mark Sizes D1 [mm], D2 [mm] and D3 [mm] C02_03
Window Size [mm] C02_04
Mark Image C02_05
Mark Level C02_06
Angle [deg] C02_07
Lighting Level Coax, Ring, Option C02_08
T2B5
C03 Operation Data
Items Ref. No.
PEC Recognition Set C03_01
Beam C03_02
Sequence C03_03
T2B6
2.3 Composition of Operation Data
2OM-1751
2-71303-001
C04 Set-up Data
Items Ref. No.
Conveyor C04_01
T2B7
C05 Support Pin Data
Items Ref. No.
Support Pin Set C05_01
Support Pin C05_02
The number of Pin using C05_03
Table C05_04
M-X, M-Y, Coord X, Coord Y C05_05
T2B8
2.3 Composition of Operation Data
2OM-1751
2-81303-001
2.4 Composition of Control Data
The set parameters are used to set the automatic operation and PCB transfer
control.
Reference
Refer to "3.4 Control" in Chapter 2, for the details of each item.
D01 Control Data
Items Ref. No.
Placement Mode D01_01
PCB Finishing Position D01_02
Pre-PL cmpnt thkns
PCB Top [mm], PCB Bottom [mm]
D01_03
PEC expansion correction D01_04
T2B9
D02 PCB Locate Data
Items Ref. No.
PCB detection off DLY D02_01
PCB Locate SET D02_02
PCB Locate Sequence D02_03
UP
MOVE
1st Speed DCLR SET
2nd Speed DCLR SET
Z Clamp
Opr. waiting time
Opr. ST DLY timer
D02_04
DN
MOVE
1st Speed DCLR SET
2nd Speed DCLR SET
Backup axis DN start DLY
D02_05
SW POSN of 1st / 2nd D02_06
Replace vacuum sensor D02_07
PCB position of contact D02_08
UP
MOVE
1st speed DCLR SET
2nd speed DCLR SET
Vac. Ctrl. delayed starts
Vac. Wtg. Timer
Z clamp waiting time
D02_09
T2B10
