Section 4 Air Piping Diagram
0005-002-(M741X-A--1101) 4-6 Tg0250-PM-MD
Main Body Section (Detail D)
0.39 MPa
(4 kgf/cm
2
)
0.49 MPa
(5 kgf/cm
2
)
S S
Section 4 Air Piping Diagram
9910-001-(M741X-A--1102) 4-7 Tg0250-PM-MD
Feeder Base Section
No. Name Q'ty
1 Air Valve Set 4
1-1 Manifold 4
1-2 Solenoid Valve 76
2Plug 8
3 Silencer 4
4Air Cylinder 76
5 Light Coupling 6
6Air Cylinder 4
7Union 2
8Union 5
9Union 2
10 Union 2
11 Union 2
12 Plug 1
Section 4 Air Piping Diagram
9910-001-(M741X-A--1102) 4-8 Tg0250-PM-MD
Feeder Base Section (Detail A)
