FLEXICUT User's Guide
Version 2
19
Screen : Home Page
Switch on the machine by pressing on the O/I switch on the back of the machine (machine should be plugged
in). After a short delay, the screen will turn on and display the page below.
A : Cutting menu
B : Parameters menu
SETTINGS
When selecting settings, you have to enter the machine code (the factory password is 1234). When the code
is validate, the screen below appears.
A : Back to the previous screen
D : Machine’s code activation and
B : Back to the home screen
E : choice of type of machine
C : Clean system activation (cf. chapter on cleaning)
A
B
B
C
D
E
A
FLEXICUT User's Guide
Version 2
20
You can go back to the previous screen by pressing button “A” and go back to the home screen by pressing
button “B”.
Machine Choice
You should select the working mode of the machine corresponding to the options installed.
If none of the extra tables are used, then select « A ». If the moving table (ref: 51801) is installed, select “B”.
If a fixed flat table (ref : 51802) is installed, then select “C”.
The “D” option is for the MECATOM T180.
Password activation/modification
You can lock the machine with a password. If you want activate or disactivate the code on your machine,
switch button “B”
To modify the code, press “A”. The screen below appears.
A
B
B
A
C
D
FLEXICUT User's Guide
Version 2
21
Enter the new code and press “Enter”.
Cutting
From the home screen, select “A” to reach the cutting parameters.
A
B
