SM-Series SME DB Tape Feeder User's Manual
ii
About Safety
In order to ensure user safety and prevent property damage, the items to be observed are
indicated using safety symbols.
Cautions to be exercised for safety are described in this manual as follows:
Danger Indicates an imminently hazardous situation which, if
remarks following this symbol are not observed, will result in
death or serious injury. Therefore, instructions must be
followed without fail.
Warning Indicates a potentially hazardous situation which, if remarks
following this symbol are not observed, will result in death or
serious injury. Therefore, instructions must be followed
without fail.
Caution If remarks following this symbol are not observed, damage
to the machine, embedded program, data, etc. may occur,
or accidents involving personal injury may occur. Therefore,
instructions must be followed without fail.
Basic items to be observed in common when using the tape feeder are classified as
follows:
Warning The tape feeder must be repaired and calibrated only by our
CS engineer or a person who has received specialized
training.
Do not operated the tape feeder with wet hands or hands
stained with foreign materials.
Caution Perform maintenance of the tape feeder periodically.
When installing or transporting the tape feeder, exercise
care so that the tape feeder does not drop or collide with the
feeder base, causing damage to the tape feeder.
Preface
iii
Concerning Storage
Basic items to be observed with regard to the storage of the Tape Feeder are as follows
Cautions against tape feeder storage and tape feeder reel replacement
Do not replace or keep reels with tape feeders being stacked.
The components of the tape feeder may be damaged or deformed.
Do not pile feeders up on one another
Do not store the feeders in places where temperature and humidity level are high
Do not keep tape feeders in a place with temperatures higher than 40°C or high
humidity. If the tape feeder becomes rusty or the circuit board has moisture, an error
may occur to the driving module or electronic circuits.
Do not store the feeders in places where temperature and humidity level are high
SM-Series SME DB Tape Feeder User's Manual
iv
Do not store feeders in a location where magnetism is generated
Do not keep tape feeders in a place where magnetism is generated. If the area from
which a part is picked up in the tape feeder is magnetized, a part feeding error may
occur.
Do not store feeders in a location where magnetism is generated
Do not store feeders in the place where there is the presence of oil and organic solvents
Do not keep tape feeders in a place where oil or organic solvent exists. The tape feeder
may be damaged or reel components may be damaged if stained with oil or organic
solvent or a defect may occur to a PCB.
Do not store feeders in the place where there is the presence of oil
Avoid collision
Exercise care so that the tape feeder does not collide with another tape feeder or other
materials. The tape feeder may be damaged, causing its performance to be reduced.
Avoid collision
