2-30
SM-Series SME DB Tape Feeder User's Manual
Error The letter ‘E’
and figures blink
in turn.
The figure refers
to the type of
error.
E0: Occurred overcurrent more
than 1.7A
Cause of motor failure or cable
damage.
Contact our C/S company.
E1: Origin Sensor Error
Check for motor rotation
Check for foreign materials on
the sensor
Perform homing by force by
pressing the function key
E2: Automatic initialization error
Reinstall the tape in the tape
feeder
Defective vinyl tape discharge
E3 / E4: Service Mode
Contact our C/S company.
E6: Pitch Counter Error
Check for motor rotation
Overload occurred caused by a
part jamming between the tape
guide and sprocket
Check for foreign materials on
the sensor
H: Not Homing
Press the Home button to
perform homing
C: Disconnection of communication
with IT system
Check whether the ITS
program has been executed
Check whether the probe pin
has been damaged. If
damaged, replaced the probe
pin
Feeder State LED Display State Explanation
2-31
Operation of the Feeder
Caution Unauthorized modification of internal parameters may lead
to malfunction of the feeder and damage to its components.
We do not provide warranty for problems that occur due to
unauthorized modification of internal parameters.
Homing - ETC Home Button All errors except for the E0 error
are reset along with the homing
movement.
Feeder State LED Display State Explanation
2-32
SM-Series SME DB Tape Feeder User's Manual
2.9. Precautions during use
Exercise the following precautions while using the tape feeder:
1) Do not leave the tape feeder unattended for long period of time.
2) When foreign materials exist on the tape feeder, remove them immediately.
3) Do not bend the tape by applying excessive force.
4) Keep the tape reel from being contaminated. Contamination of the tape reel may cause
a problem to the splicing function.
2.10. Feeder Registration
Regarding feeder registration, please refer to ‘Administrator’s Guide(Chapter8. Feeder
Setup)’ or ‘EasyOLP Manual’ for SLM series equipment.
