4-6 SM-Series SME DB Tape Feeder User's Manual Part turnover/edge- standing Defect occurred to the T ape E0001 T ape guide is d eformed E0002 Weak a dhesive power Defective tape guide maintenance E0003 A part droppe…
4-5
Trouble Shooting
4.2. Process Trouble Shooting
4.2.1. Pickup Error (Increased Dump Rate)
Parts are not picked up - Errors causing parts to not be picked up
Part Supply Error
Abnormal
noise
Foreign materials exist on the
sprocket.
Remove the foreign materials.
Foreign materials exist between the
gears in the cover (do not
disassemble the cover without
authorization).
Contact our C/S company.
Failure of the index or vinyl
discharge motor.
Contact our C/S company.
Generation
of dust and
powder.
Sharp edge is created at the tape
guide.
Remove sharp sections or
replace the tape guide.
Defective bonding between tape
and vinyl, excessive dust on the
tape
Contact the corresponding
manufacturer or our C/S
company.
When the
loss rate of
a specific
part is high
due to
static
electricity
Defect due to the characteristics of
a part
Prevent part feeding errors
due to static electricity by
attaching a magnet
For the 12mm / 16mm tape
feeder, discharge the vinyl
tape through the front slit of
the tape guide for
production.
For more details, please
contact STS or our local
agent
Problem Possible Cause Measures
Cause Description Remarks
Tape installation error Incorrect installation of tape reel in
the tape feeder
E0000
4-6
SM-Series SME DB Tape Feeder User's Manual
Part turnover/edge-
standing
Defect occurred to the Tape E0001
Tape guide is deformed E0002
Weak adhesive power
Defective tape guide maintenance E0003
A part dropped down below
Incorrect part supply speed setup E0004
Defective feeding Defective feeder maintenance E0005
Defective feeding motor operation of
the tape feeder
E0006
Y-axis distorted E0007
A part beside the
corresponding part
jumped off
Pickup Z setup error occurred. E0008
The down movement for pickup is
fast.
E0009
4-7
Trouble Shooting
4.2.1.1. Part Non-pickup Error
E0000 Tape is not set properly in the tape feeder.
[Cause]
Sprocket teeth of the tape feeder are not engaged correctly into the tape holes.
[How to Check]
Check whether the sprocket is engaged into tape holes properly.
Check whether the tape reel is not set in the tape feeder with the cover tape not being
peeled off.
[Measures]
Engage the sprocket teeth of the tape feeder into the tape holes correctly.
E0001 Defect occurred to the tape
[Cause]
When removing the cover tape by hand, a part is detached along with the cover tape
since it is stuck on the cover tape.
[How to Check]
When removing the cover tape manually, check whether a part is lifted due to its being
stuck to the tape.
[Measures]
Change the tape
E0002 Tape guide is deformed
[Cause]
The tape guide does not move smoothly or it is deformed due to impact
[How to Check]
Check whether the tape guide moves smoothly by moving the tape guide. Then check
for its deformation.
[Measures]
Contact our designated C/S company (STS) or local agent. (Replace the tape guide)
E0003 Defective tape guide maintenance
[Cause]
Foreign material is jammed in the cover tape slot of the tape guide.
Foreign materials or parts such as chips are jammed between the tape guide and the
main body of the feeder or between the tape guide and tape.
[How to Check]
