3 Camera Calibration in SW 605.xx Stations 3.4 XML Report (SW 605.xx) 64 Operating Manual / Bedienungsanleitung Camera Calibration FCCS digital Kamerakalibrierung FCCS digital 04/2020

3 Camera Calibration in SW 605.xx Stations

3.4 XML Report (SW 605.xx)

Operating Manual / Bedienungsanleitung Camera Calibration FCCS digital Kamerakalibrierung FCCS digital 04/2020 63

Parameter name Value of camera Comment

<Diagnostics

StateOfGSM ="4"

LastError ="00" />

<HardwareState

ChecksumEEPROM ="OK"

Selftest ="OK" />

- <SensorSpecificData

PixelScale ="124">

<FieldOfView

StartX ="204"

StartY ="8"

SizeX ="1220" No. of pixels (image points) per line in field of

vision

SizeY ="1220" /> No. of pixels (image points) per column in field

of vision

<Extended

MaxIllum ="10"

MinSleep ="10"

ModusTrigger ="4"

ModusTransmit ="0"

ModusEnable ="2"

ModusSense ="12"

ModusExposure ="5"

Can0ToPlane ="1"

Can1ToPlane ="2"

Can2ToPlane ="4"

Can3ToPlane ="8"

Can4ToPlane ="16"

Can5ToPlane ="32"

FlashDelay ="0"

FinishDelay ="0"

ModusFlash ="0"

TriggerExposure ="20"

MaxExposure ="200" />

</SensorSpecificData>

</Sensorsystem>

3 Camera Calibration in SW 605.xx Stations

3.4 XML Report (SW 605.xx)

64 Operating Manual / Bedienungsanleitung Camera Calibration FCCS digital Kamerakalibrierung FCCS digital 04/2020

4 Camera Calibration in Stations from SW705.03

4.1 Camera calibration from station software 709.0 und 712.1

Operating Manual / Bedienungsanleitung Camera Calibration FCCS digital Kamerakalibrierung FCCS digital 04/2020 65

4 Camera Calibration in Stations from

SW705.03

NOTICE

For report purposes you can find two XML files for each camera in C:\SR-Daten

\FCCS.

The file names have a time stamp and the following identifiers:

- gantry name

- camera type name

- before / after calibration

- date stamp

Example: Gantry_1_CameraID_25_after_FCCS_2008_06_06_14_01_28.xml

NOTICE

From SW709.0

On the station computer: C:\Sirio\Work\MaintenanceReports

On the SIPLACE Pro computer: C:\MaintenanceReports

4.1 Camera calibration from station software 709.0 und 712.1

The maintenance GUI was introduced with station software 709.0 and the function "Calibrating illu-

mination" (now "Camera verification") was moved there.

In addition, the camera check has been extended to include the function "Check camera for soiling"

from station software 712.1. This function extension can be performed separately or as a precursor

to the camera check. See also 4.5 "Calibration sequence in SW 7xx.xx" [}69]

4.2 Preparations

NOTICE

Dry run

To ensure the successful camera calibration for the complete line, it is recommended to

perform a dry run of the camera calibration without saving the calibration values.

This is necessary, because aborting the calibration will lead to different illumination values

of the cameras in the line. The reliable detection of components throughout the whole line

cannot be ensured until the camera in question has been replaced and all cameras in the

line have been re-calibrated.

To ensure that customer setups do not need to be changed, a black calibration tool carrier is

moved into PCB conveyor 1, is optically centered and clamped into place, the presence of the

white balance calibration tools is checked and illumination calibration (white balance process) is

started.

NOTICE

Pre-requisites: nozzle configuration, conveyor width etc.

You can leave the SW wizard at any time in order to pick up the required nozzle types via

the single menus.
