2 System components and configurations Installation manual SIPLACE Pro Edition 01/2007 US 12 2.2 System configurations There are v arious config urations for th e SIPLACE Pro installation depending o n your produc tion e…
Installation manual SIPLACE Pro 2 System components and configurations
Edition 01/2007 US
11
2 System components and configurations
2.1 Overview of system components
A complete installation of SIPLACE Pro consists of the following components. 2
Fig. 2 - 1 Overview of SIPLACE Pro system components
Æ Please read the documents "Configurations for SIPLACE Pro" and "Navigation Guide for
Installation". You will find the documents on the Installation CD for SIPLACE Pro (Folder
"Documentation").
2 System components and configurations Installation manual SIPLACE Pro
Edition 01/2007 US
12
2.2 System configurations
There are various configurations for the SIPLACE Pro installation depending on your production
environment. 2
2.2.1 "Stand alone" configuration
Install all software components on one computer. This computer then functions as both server and
client. If installing on one computer, we recommend using a computer with at least 512 MB disk
space; a high-performance computer is advantageous. 2
2.2.2 "Client/Server" configurations
If installing on separate computers, you work with one computer as the dedicated server and one
or more other computers as clients. 2
Example of a client/server configuration:
MS SQL Server, SIPLACE Pro Database, Line Control Server and SIPLACE Pro Server are in-
stalled on the server computer. One or more clients can work with this server computer. SIPLACE
Pro Desk, SIPLACE Pro Interface and Line Control GUI are installed on the client computers. 2
Note
This configuration is not mandatory. For example, you can also install Line Control Server on a
client computer or a separate computer.
It is also possible to change the configuration subsequently. 2
Warning:
Installation on separate computers cannot be performed via the network. Install the individual
components on separate computers by calling up the setup function for the components locally on
each destination computer. 2
Installation manual SIPLACE Pro 3 Important preparations prior to installation (Software configuration)
Edition 01/2007 US
13
3 Important preparations prior to installation
(Software configuration)
All computers must have been set up and prepared appropriately in advance for the complete in-
stallation of SIPLACE Pro to function correctly. 3
These preparatory measures demand knowledge about the administrative functions of Windows
and SQL Server. Please contact your system administrator for assistance if required. 3
This installation guide only describes the procedure for a version of installation called "stand alone
installation" and "standard configuration". 3
Important:
The following steps are essential before conducting the installation of SIPLACE Pro
- Windows 2000 Server with SP4 and SQL 2000 with SP4, or
- Windows 2000 Professional with SP4 and MSDE 2000* with SP4, or
- Windows 2003 Server Standard Edition (optional with SP1) and SQL 2000 SP4, or
- Windows XP Professional with SP1 or SP2 and MSDE 2000 with SP4,
- Installation of Internet Explorer 6.0
- Microsoft .NET Framework 1.1
- Microsoft .NET Framework 1.1 SP1
- Furthermore, you require Windows 2000/XP administrative rights for all computers on which
you are installing SIPLACE Pro. 3
Æ Network access rights must have been set up in order to permit data exchange with the
UNIX line computer.
3
