Installation manual SIPLACE Pro 1 Introduction Edition 01/2007 US 9 1.3.2 SIPLACE Pro Client The following Hardware is recommended for t he SIPLACE Pro Client: 1 – Pentium 4 with 2.4 GHz or higher – 4 GB hard disk – 512 …
1 Introduction Installation manual SIPLACE Pro
Edition 01/2007 US
8
1.3 System requirements
The following hardware is required for a successful SIPLACE Pro 3.2 installation. 1
1.3.1 SIPLACE Pro Server
The following Hardware is recommended for the SIPLACE Pro Server: 1
– Pentium 4 with 2.4 GHz or higher
– 2x 20GB hard disk
– 1024 MB memory (512 MB min.)
– Backup drive (e.g. DAT)
– 21” screen (19’’ min.)
– optional SR-UPS
The following Software is recommended: 1
– Windows 2000 Server with SP4 and SQL 2000 with SP4, or
– Windows 2000 Professional with SP4 and MSDE 2000* with SP4, or
– Windows 2003 Server Standard Edition (optional with SP1) and SQL 2000 with SP4, or
– Windows XP Professional with SP1 or SP2 and MSDE 2000 with SP4 and
– Microsoft .NET Framework 1.1*
– Microsoft .NET Framework 1.1 SP1*
* delivered with the SIPLACE Pro installation CD-ROM 1
Note:
A hard disk with 500 MB or more free space should be used for installation (without the operating
system installed there should be at least 1 GB free space). 1
Note:
Windows 2003 Server SP1 is supported, but not required for the SIPLACE Pro installation. 1
Installation manual SIPLACE Pro 1 Introduction
Edition 01/2007 US
9
1.3.2 SIPLACE Pro Client
The following Hardware is recommended for the SIPLACE Pro Client: 1
– Pentium 4 with 2.4 GHz or higher
– 4 GB hard disk
– 512 MB memory
– 21” screen (19’’ min.)
The following Software is recommended: 1
– Windows 2000 Professional with SP4 and MSDE* 2000 with SP4, or
– Windows XP Professional with SP1 or SP2 and MSDE 2000 with SP4 and
– Microsoft .NET Framework 1.1*
– Microsoft .NET Framework 1.1 SP1*
* delivered with the SIPLACE Pro installation CD-ROM 1
Note:
A hard disk with 500 MB or more free space should be used for installation (without the operating
system installed there should be at least 1 GB free space). 1
Note:
Windows 2003 Server SP1 is supported, but not required for the SIPLACE Pro installation. 1
1.3.3 SIPLACE Stand Alone Configuration
The following Hardware is recommended for the SIPLACE Pro Server: 1
– Pentium 4 with 2.4 GHz or higher
– 20 GB hard disk
– 1024 MB memory (512 MB min.)
– Backup drive (e.g. DAT)
– 21” screen (19’’ min.)
– optional SR-UPS
The following Software is recommended: 1
1 Introduction Installation manual SIPLACE Pro
Edition 01/2007 US
10
– Windows 2000 Professional with SP4 and MSDE* 2000 with SP4, or
– Windows XP Professional with SP1 or SP2 and MSDE 2000 with SP4 and
– Microsoft .NET Framework 1.1 *
– Microsoft .NET Framework 1.1 SP1*
* delivered with the SIPLACE Pro installation CD-ROM 1
Note:
Windows 2003 Server SP1 is supported, but not required for the SIPLACE Pro installation 1
