Installing Primergy TX150 S8 with Windows Server 2008 R2 04/2014 Edition
10
The BIOS settings modifications are now done and you will need to save the changes.
► Press the → (right arrow) key, until the "Save & Exit" menu is displayed.
Figure 2-6: Save & Exit menu with "Save Changes and Exit" selected
► With the option Save Changes and Exit selected, press the ENTER key.
Figure 2-7: "Save configuration and exit?" question
► When asked for Save configuration and exit?, leave the option Yes selected and press the
ENTER key.
Installing Primergy TX150 S8 with Windows Server 2008 R2 04/2014 Edition
11
3 Installation of Windows Server 2008 R2
The following chapter describes the whole installation process of Windows Server 2008 R2 on the
TX150 S8 Server using the delivered media from Fujitsu.
First, you will need the ServerView DVD that is displayed in the following figure.
Figure 3-1: Serverview DVD containing the guided installation (version might be updated)
► Start the server and immediately insert the ServerView DVD.
After the system has started from the DVD, the following options appear for a short time.
Installing Primergy TX150 S8 with Windows Server 2008 R2 04/2014 Edition
12
Figure 3-2: Options when booting from ServerView DVD
► Ensure that the first option ServerView Installation Manager is selected and press the ENTER
key.
NOTICE
The boot options will only be displayed a couple of seconds
If you don't press a key within about 15 seconds, the boot options menu will be skipped.
The boot process might take some time. After that, the language selection should be displayed.
Figure 3-3: ServerView language selection
► Select the language you understand by clicking on the appropriate language button.
