Installing Primergy TX150 S8 with Windows Server 2008 R2 04/2014 Edition
17
The Configure your Unattended Operating System Installation screen appears.
Figure 3-9: Unattended Operating System Installation Configuration screen with Windows Server 2008 R2 Foundation
selected
► In the dropdown boxes, select Windows, MS Windows Server 2008 R2, Windows Server 2008
R2 Foundation, Service Pack 1 as displayed in the figure above.
► Click the Next button at the bottom of the screen.
Installing Primergy TX150 S8 with Windows Server 2008 R2 04/2014 Edition
18
The Configuration of Disks and RAID Controllers screen appears.
Figure 3-10: Configuration of Disks and RAID Controllers screen with default options (depending on previous configuration,
this screen might differ a bit)
Installing Primergy TX150 S8 with Windows Server 2008 R2 04/2014 Edition
19
► Modify the default settings as displayed in the following figure.
Figure 3-11: Configuration of Disks and RAID Controllers screen with custom options (depending on previous configuration,
this screen might differ a bit)
► For RAID level 1, select RAID-1. This configures a Mirror RAID.
NOTICE
Select/change RAID options carefully
In this manual, RAID level 1 is used for data security. RAID 1 requires two hard disks at
least. In most cases, changing the RAID level afterwards causes existing data on the
involved disks to get lost. So, you should ensure to select the proper RAID level first
before setting up the computer with important data. For more information on RAID levels,
please consult the manual for your RAID controller or search in internet for RAID
documentation.
► For Boot Partition Size, select manual and enter the value 150000 MB to reserve about 150 GB
for the boot partition (the Windows "C:" drive).
NOTICE
Whole disk with single partition
If you leave the default settings for boot partition size, a single partition containing the
whole disk will be created. After that, you will have to use a partition manager tool if you
want to split the system into more partitions.
► Click the Next button at the bottom of the screen to continue.
