Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition
11
4 Compatible Mode
Some station software versions may be used as lower versions in compatible mode. This means
that the new functions of the current version can be used in the compatible version as far as
possible.
The compatible mode is provided to operate stations with lower line software versions in order to
keep the line software version in case of a station upgrade.
The 707.1 SP2 station software version can be used as Version 706.2 SP2© in compatible mode
on placement machines that do not run with the 707.x station software only. I.e., the compatible
mode may not be used on a CA4 placement machine.
The visibility and functionality of the new functions in compatible mode are explained in the
following table.
Compatible Mode Meaning
Complete
Complete function support.
Compatible The function is visible and executable at the station. However, new add-
ons in the station software or in the line products are not supported.
Hidden The function is invisible/inactive, e.g. due to licensing or unsupported
SIPLACE Pro download/upload.
Not supported
The function is not supported, e.g. because of failing hardware.
Table4-1: Visibility and functionality in compatible mode
The respective visibility/functionality in compatible mode is specified for the new features in
chapter 6.
The compatible mode can be activated under Settings – SIPLACE station interface clients on
the GUI.
Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition
12
5 Features of the 707.1 SP2 Station Software Version
All features of the 701.xx – 707.SP1 station software versions are also supported in the 707.1 SP2
station software version that does not contain any new features.
NOTICE
If the station software runs in Windows 7, the station computer has to be equipped with
at least 2 GB memory. If necessary, station computers in the field have to be exchanged
or upgraded with a memory extension. Please refer to the Technical Information TI2014-
09E04.
Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition
13
6 Features of the 707.1 Station Software Version
NOTICE
Detailed information about the functions can be found in the Online help for the station
software.
All features of the 701.xx – 707.0 station software versions are also supported in the 707.1 station
software version. The main features of the 707.1 station software version are listed below.
6.1 Twin Head / CPP Placement Heads on SIPLACE CA-Series
Compatible mode: Not supported
Additionally to the C&P20 M placement head, the CPP and Twin Head (also Twin Head HF)
placement heads are supported on the SIPLACE CA-series placement machines as of this station
software version with the following restrictions.
– Stationary cameras can only be installed on the locations 1 and 3.
– The Twin Head can only be installed on location 3.
– The CPP placement head is only supported in the high position on SIPLACE Wafer Systems.
CPP placement head
The CPP placement head can be used in Pick&Place mode and on SIPLACE Wafer Systems as
well. FlipChip and DieAttach modes are supported on the SIPLACE Wafer Systems. Dip modules
may be used.
The nozzle changer for the CPP placement head has 5 magazines for 20xx nozzles with 12
garages each and 1 magazine for 28xx nozzles with 9 garages. If desired, this configuration may
be changed, e.g. 6 magazines for 20xx nozzles.
The 33 component camera type is supported for placement in Pick&Place mode and the 30
component camera type on SIPLACE Wafer Systems.
Twin Head
The Twin Head is used in Pick&Place mode only.
The nozzle changer for the Twin Head has maximum 12 magazines with 2 garages each on the
locations 1 and 3 and maximum 10 magazines with 2 garages each on the locations 2 and 4.
The 33 and 25 component camera types are supported.
Available placement head configurations on SIPLACE CA-series
4*C&P20 M
2*C&P20 M in PA1 and 2*CPP in PA2
4*CPP
2*C&P20 M in PA1 and CPP / TH in PA2
2*CPP in PA1 and CPP / TH in PA2
