Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition
39
D1-97968401 The software hung up if you tried to reject the component after a dp axis
timeout in order to make a reference run.
D1-97987901 There was an unhandled exception error and the station software
console hung up.
D1-98164001 Consecutive fault after a HW problem: the software hung up when a feeder
was removed.
D1-98199201 The GUI was frozen and the machine had to be restarted.
D1-98229601 After restart, a software error was always displayed on an SX4 placement
machine.
D1-98660211 On a CA-series placement machine with SIPLACE Wafer System and LDU,
the waiting position of the C&P20 placement head was directly above the
LDU.
D1-98957051 The ink spots of the robustness measurement were not correctly displayed.
D1-98990480
D1-98990432
D1-98990525
D16840-20813
Sporadically, the software hung up and displayed an unhandled
exception.
D1-99001901 If the placement of a component wass skipped it could not be reactivated.
D1-99338501 There was an unhandled exception when the SIPLACE Wafer System
was restarted.
D1-99346831
D1-98747909
D1-99789341
eSW: after every placement cycle there wass a height reference run for the
nozzle 2033 (the component sensor had problems to recognize the
components).
D1-99373901
D17305-4007
The WPC controller board did not work when the WPC BIOS got updated or a
new controller from the stock was installed.
D1-99780701 The C&P20 was placing slowly because the star was moving in energy save
mode when picking up or placing.
D1-99876401 A carrier with 12 magazines was mounted on an X3S placement machine with
Twin Head on gantry 3. Although each magazine could be reached by the TH
the 12th magazine could not be configured within the station.
D1-99907132 Unexpected reboot of the software.
D1-99924198 After a problem with an open safety circuit the software did not start again.
D1-100196301 30016 Unhandled exception error: the software hung up as soon as
there was an error with a component in connection with the glue feeder.
D1-100514701 The station software hung up after a complete tray was scanned into the
Teach menu and the machine had to be restarted.
D16717-13207 The station software could not be initialized.
D16747-10970 The C&P20A head only picked up components from the 1st pocket of the
manual tray.
D16807-4211 eSW: during production one segment was down and an error 40023 was
displayed that the machine cannot continue.
D16811-6525 The calculation of the reject rate was modified for station software version 706
and had to be adapted.
Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition
40
D16840-18801 Some components were missing after recovery placement when ink sports
were used.
D17134-3194 Auto recovery: the board was not unloaded from PA2.
D17241-5509 SIPLACE X4: the software stopped with the Windows unexpected stop
message.
D17280-1909
D1-92896801
D17280-3509
D17285-366
D17390-430
The software stopped on a SIPLACE X4 S placement machine as the pickup
position was corrected.
D17357-217
D16600-3607
D17263-3728
D17373-789
CPP head sporadically placed components with wrong angle (90 or 180
degrees twisted).
D17364-268 eSW: new link reference run for star and z axes (C&P20 A and C&P20 M) on
a machine with HCU.
Table 10-3: Corrected errors 707.1 station software version
Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition
41
11 Important Terms and Abbreviations
ACT Accuracy Check Tool
CA4 Machine type of the Chip Assembly (CA)-series with 4 gantries
CA4 eWLP Machine type of the Chip Assembly (CA)-series with 4 gantries
and WLFO (customer project, no release for series production)
C&P Collect & Place
CPP Collect & Place & Pick & Place
DC Dual Conveyor
DX1/DX2 Machine type with 1 or 2 gantries
DX4 Machine type with 4 gantries
EDIF Electronic Design Interchange Format
eWLP embedded Wafer Level Process
FCCS Field Camera Calibration System
GCU Gantry Control Unit (new electronic concept for X4i)
GUI Graphical User Interface
HCU Head Control Unit (new electronic concept for X4i)
HFH High Force Head
HW Hardware
MTC Matrix Tray Changer
OIS Operator Information System
PA Processing area
PCB Printed circuit board
SC Single Conveyor
SC SIPLACE Setup Center (external setup control system)
SW Software
SWS SIPLACE Wafer System
SX1/SX2 Machine type with 1 or 2 gantries
SX3 Machine type with 3 gantries
SX4 Machine type with 4 gantries
TH Twin Head
TH HF Twin Head High Force
Twin VHF Very High Force Twin Head
VC Vision computer
VCU Vision Control Unit
VHF P&P Very High Force Pick&Place
WLFO Wafer Level Fan-Out, Chip Assembly process
WPC Waffle Pack Changer
X2/X2 S Machine type with 2 gantries
