Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition
17
7 Hardware Specifications
7.1 Supported Feeder Types
The following feeders are supported by the 707.1 SP2 station software version:
– 4 mm – 104 mm X-feeder
– 2x8 mm X-feeder
– 16 mm XN-feeder
– 12 V2 X-feeder
– Surftape AX (8 mm, 12 mm, 16 mm)
– LED feeder TE
LED feeder HS
– Glue Feeder
– TrayStack Feeder AX (X4i S on location 2 and 3 only)
– SIPLACE JTF-S (X-series S and SX1/SX2 V2 only)
– SIPLACE JTF-M (X-series S, X4i S micron and SX1/SX2 V2 only)
– Arbitrary Carrier X (X-series only)
– Carrier X (XTH) (X2, X3, X4 on location 2 and 4 only)
– Carrier SX (SX1/SX2 with Twin Head and CPP head only)
– FFI feeders:
HanSan LED feeder
Top Engineering LED feeder
Data IO RoadRunners
– IPTE Multi Stick Feeder:
IPTE multi stick 60 AX
IPTE multi stick XL80 AX
– Stick feeder with X-adapter
– Label feeder with X-adapter
– Reject conveyor with X-adapter
– Dip module for X-tables (LDU_X)
– MTC2 (X2, X3, X4 on location 2 and 4, X2 S, X3 S, X4 S on location 2)
– WPC5/WPC6 (SX1/SX2, X-series S on location 2)
– SIPLACE Wafer Systems (CA-series only)
– Splice sensor X-feeder
Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition
18
7.2 Digital Camera Systems
Digital CCD cameras are used as the camera systems.
7.2.1 Component Cameras
All heads are equipped with the standard camera listed below. High-resolution cameras are
additionally available for Twin Head and CPP.
Component camera
Camera
type
CPP
head
C&P20A
head
C&P20 M
head
3)
C&P20 P
head
4)
C&P
6 x 6 mm digital
23
-
(default) -
(default)
C&P
6 x 6 mm digital
41
-
(optional)
(default)
(optional)
C&P
18.7 x 18.7 mm digital
28
(optional) - - -
C&P
27 x 27 mm digital
29
(optional) - - -
C&P
27 x 27 mm digital
30
(default) - - -
C&P
16 x 16 mm digital
38
(optional) - - -
Stat. P&P
16 x 16 mm digital
1
)
25
- - - -
Stat. P&P
55 x 45 mm digital
1)
33
(optional)
2)
- - -
Stat. P&P
32 x 32 mm digital
36
(optional) -
Table 7-1: Component cameras, part 1
1)
Not supported on the SIPLACE X4i placement machine.
2)
Only together with CPP head, with which components up to a height of 11.5 mm can be placed.
3)
Only supported on the CA-series and X4 S micron /X4i S micron placement machines.
4)
Only supported on the X-series S placement machines.
Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition
19
Component camera
Camera
type
Twin
head
VHF P&P
head
Twin VHF
head
5)
C&P12
head
C&P
6 x 6 mm digital
23
- - - -
C&P
6 x 6 mm digital
41
- - - -
C&P
18.7 x 18.7 mm digital
28
- - -
(default)
C&P
27 x 27 mm digital
29
- - - -
C&P
27 x 27 mm digital
30
- - -
(optional)
C&P
16 x 16 mm digital
38
- - - -
Stat. P&P
16 x 16 mm digital
2
)
25
(optional)
(optional)
(optional) -
Stat. P&P
55 x 45 mm digital
2)
33
(default)
(default)
(default) -
Stat. P&P
32 x 32 mm digital
36
(optional) - - -
Table 7-2: Component cameras, part 2
5)
Only supported on SX1/SX2 V2 placement machines with one gantry at a higher position.
7.2.2 Board Cameras
Board camera
Camera
type
SIPLACE
X-series /
X-series S
SIPLACE
SX-
series
SIPLACE
DX-series
SIPLACE
CA-series
28 digital 34 (default) (default) (default) (default)
28 digital 34HU (default)
1)
Multicolor 28 digital 24 (optional)
Table 7-3: Board cameras
1)
Only supported on the SX1/SX2 V2 placement machines with one gantry at a higher position.
