Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition

D17486-2807

D1-103881989

The position correction did not work correctly for alternative component tracks.

D1-93860054 Events which were sent from Setup Center to Facts (foil torn) were not ok.

D1-97048506 Feeder settings upload did not work correctly.

D1-99346831

D1-98747909

D1-99789341

After every placement cycle there was a height reference run for the nozzle

2033 (the component sensor had problems to recognize the components).

D1-99367001 An undefined dp axis hardware error was displayed in the message window

during booting. However, the machine ran without any problems.

D1-99789301 The MAC Test button was available although the function could not be used.

Table 10-1: Corrected errors 707.1 SP2 station software version

10.2 707.1 SP1 Station Software

The 707.1 SP1 station software version contains all error corrections of the previous 701.xx –

707.1 versions. Additionally, the following errors have been corrected in this version:

Error no. Error description

D1-93125201 The service notification for the SX gantry was not correct.

D1-100758981 After a foil torn error the feeder LED got green although the track was locked.

D1-85092201

D1-96871701

D1-98744850

The station did not send "waiting for PCB" events and SPM and SIPLACE

Explorer just displayed "productive" status).

D1-96491101 eSW: travel range limits of the y axis were not ok; after the removal of the

prepared gantry and installation of the long buffers the newly detected travel

range was too big (> 563mm).

D17397-2558

D1-100886301

eSW: Sporadic problems with connection of feeder or LDU and FCU.

D1-96910701 eSW: after having taught the pickup position there was an unspecified

hardware error.

D1-101493102 If a head mapping in station software 706 was interrupted and continued (but

not restarted from the beginning) the machine did not work anymore after

update to station software 707.

D1-101571301 Reset all changes was set when the pickup position was taught. After that,

the original SIPLACE Pro position was displayed instead of the position

recognized by the component pocket recognition.

D1-101450551 The software displayed "No head mapping file" after mapping.

D1-103970041 Y-axis mapping could not be calibrated on an SX1/2 placement machine.

Table 10-2: Corrected errors 707.1 SP1 station software version

Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition

10.3 707.1 Station Software

The 707.1 station software version contains all error corrections of the previous 701.xx – 707.0

versions. Additionally, the following errors have been corrected in this version:

Error no. Error description

D1-71191701 The PCB barcode could not be read by the PCB camera due to license

problems.

D1-77328408

D1-84415501

D1-94337745

Components could not be skipped if there was no device on the component

table.

D1-79643401 The zero point calibration of the pressure control unit was possible although

the machine was producing

D1-81436552 Nozzle reference run was not possible after nozzle change.

D1-85452101 Old data from the preceding setup was displayed which lead to different

errors.

D1-87534201 Components from a tray were not counted if they were thrown away.

D1-87545901

D1-96021501

There was a conflict between the CPP placement head and a tray with high

components on a SIPLACE SX2 V2 placement machine.

D1-87903901 Twin Head: empty error message when the reference run did not succeed due

to a missing nozzle.

D1-88066301 The connection between OIS and station was sporadically interrupted and OIS

lost data.

D1-88334910 Error message 31806 Cannot write data, parameter: feeder in

product, value: 0

was displayed after table changes and logoff.

D1-88731605 Lamp control and synchronous dual conveyor: although the machine stopped

the green lamp was on.

D1-88931317 On the GUI you got the message Exclusively deactivated by Setup

Center - component verification check failed, the production

stopped and you had to scan the component barcode.

D1-88937643 An SX V2 placement machine stopped after erroneous tray fiducial

measurement.

D1-91269001 eSW: Motor moving error 35392 due to incorrect acceleration value.

D1-91468501 The board could not be aborted.

D1-92374501 The head had to wait for the squeegee operation during a head cycle.

D1-92565241 eSW: the board on conveyor lane 2 was not transported.

D1-93860054 After a torn foil, events came from Setup Center after the processing in Facts.

Facts.

D1-93989701 Sporadically, barcodes were not read on a SIPLACE X4i S placement

machine.

D1-93990304 When Traceability was used together with PCB Barcode, manual entering of

the barcode could not be enabled.

Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition

D1-94232111 After a power failure no placement heads were recognized.

D1-94349018 SirioConsole.exe stopped after a feeder change.

D1-94806401 With a new job a modified head configuration was reported (if the nozzle

reference run and the width adjustment were carried out together).

D1-95201357 Twin VHF: the z axis already moved up although the main axes were still

moving (only in case of pickup offset).

D1-95580941 The Restore MA Data function did not work.

D1-95290001 After the vacuum too low message the software stopped with an unhandled

exception.

D1-95979301 CA placement machine: Chuck was not measured correctly.

D1-96020401 An unhandled exception occurred (error 30016 with error 32602) and the

machine had to be rebooted.

D1-96027749 Wrong placement positions were used in the dry run.

D1-96214973 The software stopped during nozzle reference run.

D1-96226401 Sometimes the iSkip files were missing  additional traces implemented.

D1-96228901 A SIPLACE SX2 placement machine lost the calibration chip position during

head calibration.

D1-96228991 During calibration on a SIPLACE SX2 placement machine, the selected

segments were displayed in gray.

D1-96235830 The software stopped when trying to return the nozzle.

D1-96569001 eSW: Placement area 1 was waiting for PA2; placement began after PA1 had

been completed.

D1-96604912 The virtual keyboard had no digits.

D1-96763201 30399 Unexpected reboot from subsystem detected.

D1-96798401 It was not possible to specify two boards for a recipe with virtual PCB stacking.

D1-96874101 The software hung up after image recording of a tray.

D1-96899001 The board was not moved into the next machine after fiducial teaching.

D1-97063707 Inspite of ink spot to omit panels, all panels were completely placed.

D1-97108801 eSW: The statistical data of the head did not have any content.

D1-97140001

D17077-4770

There was an offset of ink spots in X4i S and inaccurate placement after the

machine cover was opened.

D1-97158707 Vision dumps could not be opened on a CA-series placement machine.

D1-97649301 Two buttons were available for the same function on the GUI.

D1-97851847 The button for the extended conveyor interface was missing on the GUI.

D1-97954814 An SX-series placement machine delivered erroneous Trace data.
