Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition

D1-104103541 In case of a yellow board, the information was sometimes missing from which

machine the error came.

D1-104132901 The WPC reported an error message when a tray with high components was

refilled.

D1-104310307 The conveyor 2 collided with the support pins. Now it can be configured that a

message window always pops up and tells the operator to remove the pins.

D1-104319313

D1-105206517

Sometimes the head stopped above the feeder pick up position.

D1-104503743 The 32608 waiting until stopped error message was displayed for

head 4 and the machine had to be restarted.

D1-104523401 During the first setup of the machine the embedded software download failed;

after reboot it was ok.

D1-104523449 The software hung up after having measured the vacuum at gantry 1.

D1-104642951 Reject rates from GUI, OIS and Explorer did not match.

D1-104893101 LED placement with placement sequence lead to a software hang-up.

D1-105195201 Machine issued the 32602 The software has stopped

unexpectedly. Shut down Windows, then restart the station

error.

D1-105647001 During production the head wanted to make a nozzle configuration check but

the head was waiting endlessly over the nozzle changer.

D1-106116303 The head stopped over the feeder table but did not do anything.

D1-106845201 eSW: There was a timeout when the "unlock all feeder" function was used.

D16840-18613 The 2x8mm x-feeder reported a foil torn error although there was none.

D16840-25113 A very high reject rate was displayed on the SIPLACE OIS GUI when boards

with ink spots were placed.

D17077-6420

D1-102963501

The C&P20 M placement heads in placement area 2 were not recognized.

D17238-1501 The software hung up when the operator scanned the component barcode

with barcode reader.

D17239-10311 The pickup point was not shown on the GUI during pickup position correction.

D17263-8714 Skipped components were not reset with the next job.

D17305-4811 A red board was displayed although no board was cancelled and the machine

produced normally.

D17305-6220 The PCB camera stopped scanning the PCB barcode.

D17383-211 There was an unhandled exception during production.

D17384-4107 The machine issued the 32602 The software has stopped

unexpectedly. Shut down Windows, then restart the station

error.

D17384-4932 The machine issued the vacuum not sufficient error.

Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition

D17486-2807

D1-103881989

The position correction did not work correctly for alternative component tracks.

D1-93860054 Events which were sent from Setup Center to Facts (foil torn) were not ok.

D1-97048506 Feeder settings upload did not work correctly.

D1-99346831

D1-98747909

D1-99789341

After every placement cycle there was a height reference run for the nozzle

2033 (the component sensor had problems to recognize the components).

D1-99367001 An undefined dp axis hardware error was displayed in the message window

during booting. However, the machine ran without any problems.

D1-99789301 The MAC Test button was available although the function could not be used.

Table 10-1: Corrected errors 707.1 SP2 station software version

10.2 707.1 SP1 Station Software

The 707.1 SP1 station software version contains all error corrections of the previous 701.xx –

707.1 versions. Additionally, the following errors have been corrected in this version:

Error no. Error description

D1-93125201 The service notification for the SX gantry was not correct.

D1-100758981 After a foil torn error the feeder LED got green although the track was locked.

D1-85092201

D1-96871701

D1-98744850

The station did not send "waiting for PCB" events and SPM and SIPLACE

Explorer just displayed "productive" status).

D1-96491101 eSW: travel range limits of the y axis were not ok; after the removal of the

prepared gantry and installation of the long buffers the newly detected travel

range was too big (> 563mm).

D17397-2558

D1-100886301

eSW: Sporadic problems with connection of feeder or LDU and FCU.

D1-96910701 eSW: after having taught the pickup position there was an unspecified

hardware error.

D1-101493102 If a head mapping in station software 706 was interrupted and continued (but

not restarted from the beginning) the machine did not work anymore after

update to station software 707.

D1-101571301 Reset all changes was set when the pickup position was taught. After that,

the original SIPLACE Pro position was displayed instead of the position

recognized by the component pocket recognition.

D1-101450551 The software displayed "No head mapping file" after mapping.

D1-103970041 Y-axis mapping could not be calibrated on an SX1/2 placement machine.

Table 10-2: Corrected errors 707.1 SP1 station software version

Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition

10.3 707.1 Station Software

The 707.1 station software version contains all error corrections of the previous 701.xx – 707.0

versions. Additionally, the following errors have been corrected in this version:

Error no. Error description

D1-71191701 The PCB barcode could not be read by the PCB camera due to license

problems.

D1-77328408

D1-84415501

D1-94337745

Components could not be skipped if there was no device on the component

table.

D1-79643401 The zero point calibration of the pressure control unit was possible although

the machine was producing

D1-81436552 Nozzle reference run was not possible after nozzle change.

D1-85452101 Old data from the preceding setup was displayed which lead to different

errors.

D1-87534201 Components from a tray were not counted if they were thrown away.

D1-87545901

D1-96021501

There was a conflict between the CPP placement head and a tray with high

components on a SIPLACE SX2 V2 placement machine.

D1-87903901 Twin Head: empty error message when the reference run did not succeed due

to a missing nozzle.

D1-88066301 The connection between OIS and station was sporadically interrupted and OIS

lost data.

D1-88334910 Error message 31806 Cannot write data, parameter: feeder in

product, value: 0

was displayed after table changes and logoff.

D1-88731605 Lamp control and synchronous dual conveyor: although the machine stopped

the green lamp was on.

D1-88931317 On the GUI you got the message Exclusively deactivated by Setup

Center - component verification check failed, the production

stopped and you had to scan the component barcode.

D1-88937643 An SX V2 placement machine stopped after erroneous tray fiducial

measurement.

D1-91269001 eSW: Motor moving error 35392 due to incorrect acceleration value.

D1-91468501 The board could not be aborted.

D1-92374501 The head had to wait for the squeegee operation during a head cycle.

D1-92565241 eSW: the board on conveyor lane 2 was not transported.

D1-93860054 After a torn foil, events came from Setup Center after the processing in Facts.

Facts.

D1-93989701 Sporadically, barcodes were not read on a SIPLACE X4i S placement

machine.

D1-93990304 When Traceability was used together with PCB Barcode, manual entering of

the barcode could not be enabled.
