Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition
40
D16840-18801 Some components were missing after recovery placement when ink sports
were used.
D17134-3194 Auto recovery: the board was not unloaded from PA2.
D17241-5509 SIPLACE X4: the software stopped with the Windows unexpected stop
message.
D17280-1909
D1-92896801
D17280-3509
D17285-366
D17390-430
The software stopped on a SIPLACE X4 S placement machine as the pickup
position was corrected.
D17357-217
D16600-3607
D17263-3728
D17373-789
CPP head sporadically placed components with wrong angle (90 or 180
degrees twisted).
D17364-268 eSW: new link reference run for star and z axes (C&P20 A and C&P20 M) on
a machine with HCU.
Table 10-3: Corrected errors 707.1 station software version
Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition
41
11 Important Terms and Abbreviations
ACT Accuracy Check Tool
CA4 Machine type of the Chip Assembly (CA)-series with 4 gantries
CA4 eWLP Machine type of the Chip Assembly (CA)-series with 4 gantries
and WLFO (customer project, no release for series production)
C&P Collect & Place
CPP Collect & Place & Pick & Place
DC Dual Conveyor
DX1/DX2 Machine type with 1 or 2 gantries
DX4 Machine type with 4 gantries
EDIF Electronic Design Interchange Format
eWLP embedded Wafer Level Process
FCCS Field Camera Calibration System
GCU Gantry Control Unit (new electronic concept for X4i)
GUI Graphical User Interface
HCU Head Control Unit (new electronic concept for X4i)
HFH High Force Head
HW Hardware
MTC Matrix Tray Changer
OIS Operator Information System
PA Processing area
PCB Printed circuit board
SC Single Conveyor
SC SIPLACE Setup Center (external setup control system)
SW Software
SWS SIPLACE Wafer System
SX1/SX2 Machine type with 1 or 2 gantries
SX3 Machine type with 3 gantries
SX4 Machine type with 4 gantries
TH Twin Head
TH HF Twin Head High Force
Twin VHF Very High Force Twin Head
VC Vision computer
VCU Vision Control Unit
VHF P&P Very High Force Pick&Place
WLFO Wafer Level Fan-Out, Chip Assembly process
WPC Waffle Pack Changer
X2/X2 S Machine type with 2 gantries
Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition
42
X3/X3 S Machine types with 3 gantries
X4/X4 S/
X4i S micron
Machine types with 4 gantries
X4i/X4i S
X4i S micron
Machine types with 4 gantries
