Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition
21
Component range for
Twin Head
With type 25
component camera
(Stat. P&P 16 x 16
mm digital)
With default type 33
component camera (Stat.
P&P 55 x 45 mm digital)
With type 36 component
camera (Stat. P&P 32 x
32 mm digital)
0201 through 16 x
16 mm
0402 through 55 x 45 mm 0603 through 32 x 32 mm
Nozzle types 5 xx (standard), 4 xx + adapter, 8 xx + adapter, 9xx + adapter
Table 7-8: Component range Twin Head
Component range for
VHF P&P head
With type 25 component camera
(Stat. P&P 16 x 16 mm digital)
With default type 33 component camera
(Stat. P&P 55 x 45 mm digital)
0201 through 16 x 16 mm 0402 through 55 x 45 mm
Nozzle types 5 xx (standard), 4 xx + adapter, 8 xx + adapter, 9xx + adapter
Table 7-9: Component range VHF P&P head
Component range for
Twin VHF head
With type 25 component camera (Stat.
P&P 16 x 16 mm digital)
With default type 33 component
camera (Stat. P&P 55 x 45 mm
digital)
0201 through 16 x 16 mm 0402 through 55 x 45 mm
Nozzle types 5xx (standard), 5xxx, 4xx + adapter, 8xx + adapter, 9xx + adapter
Table 7-10: Component range Twin VHF head
Component range for
C&P12 head
With default type 28 component
camera (C&P 18,7 x 18,7 mm
digital)
With type 30 component camera
(C&P 27 x 27 mm digital)
0402 through 18.7 x 18.7 mm 0201
*)
through 27 x 27 mm
Nozzle types 30xx
Table 7-11: Component range C&P12 head
*)
0201 components can only be placed restrictively.
Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition
22
8 SIPLACE Software Environment
8.1 SIPLACE Pro Programming System Version 11.2
The SIPLACE Pro programming system version 11.2 supports the SIPLACE X-series, X-series S,
SX-series, DX-series and CA-series placement machines with the 707.1 SP2 station software
version.
NOTICE
For a detailed description of the programming system, see the SIPLACE Pro version
description and the online help system.
8.2 SIPLACE OIS Version 11.2
Software version 11.2 of the monitoring system SIPLACE OIS supports the SIPLACE X-series,
X-series S, SX-series, DX-series and CA-series placement machines.
NOTICE
A detailed description can be found in the software description "Getting started with OIS"
and the online help system for OIS.
8.3 SIPLACE Setup Center Version 6.3
Software version 6.3 of the SIPLACE Setup Center supports the SIPLACE X-series, X-series S,
SX-series, DX-series and CA-series placement machines.
NOTICE
A detailed description can be found in the software description "Getting started with
Setup Center" and the online help system for Setup Center.
8.4 SIPLACE Traceability Version 3.6 SP1
Software version 3.6 SP1 of SIPLACE Traceability supports the SIPLACE X-series, X-series S,
SX-series, DX-series and CA-series placement machines.
NOTICE
A detailed description can be found in the “Traceability User Guide".
Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition
23
9 Restrictions
X-Feeder
Because of the mirrored gantry configuration, the number of the available tracks on gantry 2 and 4
on the X4i, SX4 and DX4 placement machines are restricted, not all of the tracks can be reached
by the placement heads. Feeders set on non-reachable tracks are deactivated automatically.
Number of nozzle changer magazines
Because of the mirrored gantry configuration, the number of configurable nozzle changer
magazines on gantry 2 and 4 on the X4i, SX4 and DX4 placement machines is limited to 4
magazines.
Nozzle types
– Nozzle types of the 4xx, 5xx, 8xx and 9xx series are not supported by the X4i, SX4 and DX4
placement machines.
– Nozzle types of the 4xx, 5xx, 8xx, 9xx, 10xx, 11xx and 12xx series are not supported by the
CPP placement head.
PCB barcode
– The PCB barcode is limited to 40 characters.
– It is not recommended to scan the PCB barcode with the barcode reader and the PCB camera
simultaneously. If both scanning types are to be used within a use case on a machine, make
sure that both readers evaluate the same barcode label.
Fiducial patterns
Asymmetric fiducial patterns (e.g. triangles) can currently only be used if the board is processed at
an orientation of 0° in the machine.
X-table
An additional table fiducial is necessary for the gantries 2 and 4 on the X4i and SX4 placement
machines.
Twin Head/HFH
– Twin Head/HFH are not supported on the X4i and DX4 placement machines.
– Not vacuum pump compatible.
– Not all pickup, dip and placement positions are accessible for both segments on the SX1/SX2
and SX4 placement machines.
CPP placement head
– Restrictions for the X2, X3, X4, X4i and SX4 placement machines can be found in the
correspondent User Guides to the X-series and in the Version Description to SIPLACE Pro.
– Not vacuum pump compatible.
– Not supported on DX series placement machines.
