Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition

SIPLACE JTF-M

– Supported on the SX1/SX2 V2, X4i S micron and SIPLACE X-series S placement machines

only.

– On the SX1/SX2 V2 placement machine no tape feeder can be placed on the location beside

the JTF-M because no empty tape channel is available.

SIPLACE Wafer Systems

– Supported on the CA-series placement machines only.

– A specific table is required.

External virtual ink spot handling

– Only possible for stations with station software from version 707.0 and SIPLACE Pro from

version 11.1.

– Physical and virtual ink spots must not be mixed.

– The board must not contain any active ink spots.

Software installation on older placement machines

During the station software installation on older X-series or X S-series placement machines that are

equipped with a CPP placement head and an MTC at location 2, a message is displayed that the

travel range has to be remeasured.

This occurs once to initialize the buffer monitoring. Thereafter, it will be checked if a retrofit has

been performed that requires a recalibration of the travel range.

CPP / Twin Head placement heads on SIPLACE CA series

– Stationary cameras may be installed on location 1 and 3 only.

– Twin Head may be installed on location 3 only.

– The CPP placement head is only supported in the high position on SIPLACE Wafer Systems.

Compatible mode: trays teachen

Trays that are taught in compatible mode cannot be stored back to SIPLACE Pro.

Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition

10 Corrected Errors

10.1 707.1 SP2 Station Software

The 707.1 SP2 station software version contains all error corrections of the previous

701.xx – 707.1 SP1 versions. Additionally, the following errors have been corrected in this version:

Error no. Error description

eSW: Improvement of the communication between star- and z-axis.

D1-101366602

D17077-6301

During machine update the I/O Module could not be reached.

D1-101855901 The station was searching for a nozzle changer on location 2 during booting.

D1-101902301 Error message 30608 Measured nozzle length too long for

nozzle of type 2820

D1-101916701 eSW: after having returned and picked up the nozzles, the "32581 Machine

has stopped: cannot close nozzle changer" error message was displayed.

D1-101995511

D1-102415701

D1-102494009

D1-102759001

D1-102896401

D1-103175201

D1-103258750

The Software hung up after eliminating track error problem when the help

video was watched. This problem is solved in 707.1.SP2; in 707.1.SP1.HF1 a

workaround is included (the video cannot be started any longer).

D1-102084601 The "z axis movement" and "filter disk check" head verification scripts could

not be started.

D1-102120223 The software hung up after switching off/on a servo on the GUI.

D1-102510901 The filter disk check for C&P20 P is done with component sensor (not with

SIPLACE Vision), hence no Vision result should be displayed.

D1-102787101 After machine start it was not possible to start production.

D1-102829301 When the station software was installed on the station computer, the

templates for the head verification report did not get installed.

D1-102868601 The setting for contamination detection of the glass plate was too sensitive.

D1-102896661 There is a function to check if there are bad tracks. If yes a window pops up

and tells about the track you should have a closer look at. If you reset the error

statistics in the GUI it had no effect on this check.

D1-102899001 Component Sensor calibration was not possible with nozzle types 4108 and

4109.

D1-103159001 The description of the Schmersal switches for input/output was not up to date.

D1-103169774 During endurance run gantry 1 always reported a wrong travel range.

D1-103205501 The LDU failed to check the planarity.

Station Software 707.1 SP2 / Version Description Ausgabe 11/2014 Edition

D1-103240701 The PCB camera could not read the 2D barcode on a SIPLACE CA placement

machine.

D1-103246641 The nozzle scan was too sensitive for the nozzles 4107 and 4109.

D1-103292201 The GUI hang up when the operator clicked on a placement position of a

loaded board and the station software had to be restarted.

D1-103295401 The software hung up during the reference run of the dp axes of gantry 2.

D1-103335501 Pickup problem WPC: the fiducials were not checked correctly and the

components from the back rows were picked up with offset or even not picked

up.

D1-103358302 The position of the reject bins at location 2 could not be reached (x-axis).

D1-103375111 Although no component used the surface inspection there was an error

message that the glass plate is dirty.

D1-103511101

D1-103511141

Machine with C&P20 P placement heads got out of memory after more than

100 hours of production.

D1-103448901

D1-104132402

Head 1 and 2 could not be referenced and the machine had to be restarted.

D1-103528032 The machine had slow response when the pickup position was taught.

D1-103548201 There was a memory leak if cover foil broken was reported.

D1-103614955 Creating the bug report needed 30 minutes and the file was very big.

D1-103624481 Teaching the placement position: the false color, zoom in, zoom out, center

and 1:1 buttons were missing in 707.

D1-103627956 After having renamed the WORK directory to WORK_Original, a new directory

was created but the component counter and the working hours were 0.

D1-103679541 For all endurance runs the amount of cycles was too high. 30-50 cycles are

enough for a faster analysis..

D1-103704658 eSW: Error message 40009 - Action at nozzle changer failed, user invention

required.

D1-103749941 The software hung up and the GUI disappeared but the heads were still

working.

D1-103910801 eSW: Feeder was permanently unlocking and locking (table 1, track 60).

D1-103930301 The reject bin was not checked by the software.

D1-103970423

D1-104091489

D1-104576801

D16877-17258

D1-104555041

A small component could not be rejected automatically but even after

removing it manually the machine did not continue but was still waiting for the

component to be removed.

D1-104045501

D1-104081501

D1-104145501

D1-104256101

D1-104260409

Sporadically, the station software did not start. Sometimes it had to be

rebooted, sometimes it had to be reinstalled.
