Cannon 50 Ohm Connectors PRECISION SMA 12 www .ittcannon.com Dimensions shown in mm (inch) Specifications and dimensions subject to change I I N N - - S S E E R R I I E E S S A A D D A A P P T T O O R R S S Plug to Plug …
Mounting Plan D (Page 40)
Straight Jack
Part Number
050 - 651 - 0000310
3,94
(.155)
9,53
(.375)
Ø1,27
(.050)
1,00
(.039)
4 POSNS
6,35
(.250)
Right Angle Jack
Part Number
050 - 653 - 0000310
14,81
(.583)
11,63
(.458)
6,35
(.250)
13,46
(.530)
3,94
(.155)
Ø1,27
(.050)
6,35
(.250)
1,00
(.039)
4 POSNS
PPRRIINNTTEEDD CCIIRRCCUUIITT RREECCEEPPTTAACCLLEESS
Mounting Plan D (Page 40)
Cannon 50 Ohm Connectors PRECISION SMA
11
www.ittcannon.com
Dimensions shown in mm (inch)
Specifications and dimensions subject to change
Cannon 50 Ohm Connectors PRECISION SMA
12
www
.ittcannon.com
Dimensions shown in mm (inch)
Specifications and dimensions subject to change
IINN--SSEERRIIEESS AADDAAPPTTOORRSS
Plug to Plug Adaptor, Straight
Part Number
050 - 673 - 0000890
22,23
(.875)
3,18
(.125)
5,56
(.219)
A
/F
2 FLATS
Plug to Jack Adaptor, Straight
Part Number
050 - 674 - 0000890
1
7,04
(.671)
Mounting Plan W (P
age 40
Jack to Jack Adaptor, Bulk Head Mount, Straight
Part Number
050 - 675 - 0000890
22,23
(.875)
1,65
(.065)
14,65
(.575)
7,92
(.312)
A/F HEX
Plug to Jack Adaptor, Right Angle
P
art Number
050 - 678 - 0000890
14,86
(.585)
11,68
(.460)
15,88
(.625)
12,70
(.500)
The surface finish on these products is passivated stainless
steel. For gold plated versions change last three digits of
the the part number from 890 to 310.
Cannon 50 Ohm Connectors COMMERCIAL SMAHeading_1
Cannon’s Commercial SMA connectors are subminiature
devices that provide repeatable electrical performance
through the frequency range DC to 18.0 GHz. These 50
ohm connectors offer minimum attenuation with low
reflection which makes them extremely popular in the
R
F and microwave industry. The MIL-C -39012 series
SMA interface ensures they can be mated with all
connectors meeting the MIL specification dimensions.
They are designed for use with a variety of subminiature
coaxial cables. This includes semi-rigid and hand
formable cables as well as the popular RG series of
flexible cable and commercial cables meeting these
dimensions.
These SMA connectors feature stand-off legs on the PCB
mount designs to enhance soldering, cleaning and
inspection. The straight plugs feature crimp / solder
contacts for speed of assembly and high performance.
SMA connectors are found in many diverse applications
including amplifiers, dividers, filters and attenuators.
The standard units are supplied in gold plate. Nickel
plated versions are available on request.
4,83
(.190)
MIN
Ø5,44
(.214)
MAX
Ø4,62
(.182)
1,98
(.078)
MAX
REFERENCE
PLANE
REFERENCE PLANE
PLUG JACK
.250-36,
UNS-2B
THD.
.250-36,
UNS-2A
THD.
2,92
(.115)
Ø1,27
(.050)
Ø0.91
(.036)
Ø4,55
(.179)
7,92
(.312)
A/F HEX
Ø1.27
(.050)
2,54
(.100)
MAX
2,54
(.100)
MAX
MMAATTIINNGG IINNTTEERRFFAACCEESS
13
www.ittcannon.com
Dimensions shown in mm (inch)
Specifications and dimensions subject to change
Key Features
• Crimp /solder contacts on straight plugs
and bulkhead jacks
• Stand-off legs on PCB mounts
• Intermateable with all SMAs to MIL-C -39012
