Cannon 50 Ohm Connectors GL OSSARY www .ittcannon.com Attenuation - Decrease in power due to resistance or mismatch in transmission line. Back Mounted - When applied to a coaxial connector it is t hat connector mounted f…
TTOORRQQUUEE WWRREENNCCHHEESS
Torque Wrench Application Jaw Size Torque Nm (in. ozs.) Torque Wrench Part Number
SMA Coupling Nut 7,92 (.312) 0,99-1,06 (140-150) T0854/12/E
SMA Assembly 7,92 (.312) 0,99-1,06 (140-150) T0854/12/E
SMA Locknut 7,92 (.312) 1,50-1,54 (212-218) T0854/12/Z4
SMB Coupling Nut N/A
SMB Assembly 5,57 (.219) 0,64-0,71 (90-100) T0854/8/C
SMB Locknut 6,35 (.250) 0,71-0,78 (100-110) T0854/10/D
SMC Coupling Nut 5,95 (.234) 0,42-0,49 (60-70) T0854/9/A
SMC Assembly (Crimp) 5,57 (.219) 0,64-0,71 (90-100) T0854/8/C
SMC Assembly (Clamp) 5,95 (.234) 0,64-0,71 (90-100) T0854/9/C
SMC Locknut 6,35 (.250) 0,71-0,78 (100-110) T0854/10/D
SSMB Coupling Nut N/A
SSMB Assembly 3,97 (.156) 0,13-0,14 (18-20) T0854/7/G
SSMB Locknut 4,75 (.187) 0,25-0,30 (35-50) contact customer service
SSMC Coupling Nut 3,97 (.156) 0,18-0,21 (25-30) T0854/7/M
SSMC Assembly 3,97 (.156) 0,13-0,14 (18-20) T0854/7/G
SSMC Locknut 4,75 (.187) 0,25-0,30 (35-50) contact customer service
BNC Adaptor Locknut 14,27 (.562) 2,9-3,1 (411-439)
Type N Adaptor Coupling 17,45 (.687) 1,2-1,6 (170-227)
Type N Adaptor Locknut 19,05 (.750) 1,8-2,2 (255-312)
Note: This is not the entire range of Torque Wrenches. Please contact customer service for details of other styles.
CCRRIIMMPP TTOOOOLLSS AANNDD DDIIEE SSEETTSS
Description
Crimp Tool without Die Set
Die Set for Cables RG178/U, 196U
Die Set for Cables RG174/U, 316/U, 179U
Die Set for Cable RG142/U
Die Set for Cable RD316
Die Set for Cable RG196
(for SSMB / SSMC Series)
Die Set for Cable RG316
(for SSMB / SSMC Series)
Old Part Number
050-000-0000000
050-000-0290000 *
050-000-0290000 *
050-000-0291000 **
050-000-0292000
-
New P
art Number
T1025/-
K29263 *2,67 (.105)
K29263 * 3,25 (.128)
K29265 5,41 (.213)
T1025/9 3,84 (.151)
T1025/1 2,67 (.105)
T1025/4 3,25 (.128)
Note:
This is not the entire range of Crimp T
ools. Please contact customer service for details of other styles.
A/F Dimensions
* 3 way die set
2,67 (.105)
3,25 (.128)
4,52 (.178)
** 2 way die set 3,25 (.128)
5,41 (.213)
www.ittcannon.com
Dimensions shown in mm (inch)
Specifications and dimensions subject to change
Cannon 50 Ohm Connectors TOOLING
59
Cannon 50 Ohm Connectors GLOSSARY
www
.ittcannon.com
Attenuation - Decrease in power due to resistance or
mismatch in transmission line.
Back Mounted - When applied to a coaxial connector it is
t
hat connector mounted from the rear of a panel with
the fixing nut on the outside.
Bandwidth - Distance between two frequencies over
which a RF or microwave device is intended to work.
Between Series Adaptor - An adaptor used to connect
two different generic types of connector.
BNC - Bayonet Nut Connector.
Braid - A weave of metal strands used as an electrical
shield for an insulated conductor or group of conductors.
Bulkhead Mount - The type of connector fitted to a
chassis using a single cut-out hole.
Cable Retention - The mechanism that joins the connector
t
o the cable.
Cable Retention Force - The axial force which a connector
/ cable join can withstand.
Captive - A component such as a contact which is held
firmly in position.
Characteristic Impedance - That impedance at which the
transmission line is intended to work. A change from the
c
haracteristic impedance along its length will cause
mismatch and loss of power.
Clamp - The holding of a cable by use of a screw thread
action.
Closed Entry Contact - A female contact which is
designed to prevent insertion of a contact larger than
that specified.
Coaxial Cable - A transmission line where the one
conductor is concentric inside another, often abbreviated
to “coax”.
C
oaxial Termination - A resistive element used to end a
coaxial line in its characteristic impedance.
Coaxial Terminator - A device for terminating coaxial cable
to a PCB or bulkhead mount (a mechanical device and
should not be confused with coaxial termination)
Conhex - Tradename covering SMB and SMC, both in 50
Ohm and 75 Ohm impedance (discontinued)
Connector Durability - The number of times a connector
can be physically mated and still maintain its specified
performance.
Contact Resistance - The measurement of the DC electrical
resistance between a pair of mated contacts. Usually
specified as being measured after a given number of
mating cycles.
Corona - A discharge of electricity caused by the
ionisation of the air around a conductor just prior to total
breakdown or flashover.
Crimp - The action of distorting a metal tube to give
intimate contact with a conductor; a good crimp should
be gas tight and not be impacted by environmental
change.
Crimp Dies - The tool inserts which determine the shape
of the distortion to create a consistently good crimp.
Crimp Tool - The tool which holds crimp dies to apply the
necessary force.
Cross T
alk - The amount of signal which may be
transferred from one signal carrying line to an adjacent
line.
Cut Off F
requency - The frequency at which the loss
exceeds a predetermined level.
Decibel (dB) - A unit of measurement of
RF power loss.
Dielectric - The insulating medium which holds the center
conductor concentric within the connector or cable.
Dielectric Constant - The electrical value of dielectric
which determines the impedance in cables or connectors
with constant diameters.
Dielectric Withstanding Voltage - The maximum voltage
that a dielectric material can withstand without failure.
Direct Solder - A common method of terminating
connectors to semi-rigid cable by soldering the cable
jacket to the connector.
Discontinuity - A dramatic change in characteristic
impedance which gives rise to a reflected wave.
Dissipation - The unused or lost energy in a system e.g.
heat.
Distortion - An unwanted change in a signal wave form.
Dummy Load - A device connected to the end of a
transmission line to absorb transmitted power and
prevent reflected energy.
Dust Cap - A mechanical device attached to the mating
f
ace of an unmated connector to prevent ingress of
contaminants and provide protection against mechanical
damage.
Electromagnetic Compatibility (EMC) - The ability of a
device to operate within its intended environment
without being effected by or generating electromagnetic
interference (EMI).
Engagement and Separation Forces - The forces required
t
o mate and unmate a pair of connectors. The forces are
usually specified as a max & min for each action.
Environmentally Sealed - A connector that is provided
with seals or other devices to prevent ingress of dust,
moisture or other contaminants while mated which might
impair performance.
Flexible Cable - A coaxial cable where the outer conductor
is flexible (usually braided).
Gigahertz (GHz) - A measure of frequency representing 1
billion Hertz (cycles per second).
I
mpedance - See ‘Characteristic Impedance’
In-Series Adaptor - An adaptor which enables the
connection of two connectors of the same generic type.
Insertion Loss - The loss of power due to a particular
component in a transmission line (e.g. cable).
Insulation Resistance - The electrical resistance between
two conductors separated by an insulating medium.
Intermodulation - The mixing of two or more frequencies
which are not intended to mix.
Interface - The two surfaces of a connector which come
into intimate contact when the two halves are mated.
Inter-series Adaptor - See ‘Between Series Adaptor’
Isolation - The measure of interaction between two or
more transmission lines.
Jack - One half of a mating pair of connectors. The jack
interface normally goes inside the plug interface.
Mean P
ower - The mean value of the rate at which energy
is transmitted from one place to another
.
Micro Strip - A transmission line consisting of a flat
conductor on a dielectric above a single ground plane.
(the ground plane is frequently a metalized face of the
dielectric).
Microwave - V
ery short electromagnetic waves.
Frequency range above 1 GHz.
MIL
-C-39012 - The generic specification covering USA
Military coaxial connectors.
MIL-C -17 - The generic MIL spec covering coaxial cables.
Mismatch - The condition in which the impedance of the
source and load are not the same. This reduces power
transfer and causes reflections.
Mounting Plan - The design of the PCB or panel cut-out
used to mount the connector.
N Connector - This was the first true microwave
connector capable of working to 18 GHz, initially
designed for test applications.
Nanohex - Trade name covering SSMB & SSMC
(
discontinued)
Noise - An external electromagnetic signal which
interferes with the desired signal.
Non-captive - A component such as a contact which does
not have a retention feature.
Passivation - This is a surface treatment applied primarily
to stainless steel. The process removes contaminating
iron particles and produces a passive surface.
Peak Power - Is the maximum power which may be
handled by a connector or cable.
Plug - One half of a mating pair of connectors. The plug
interface normally goes outside the jack interface.
P
OSNS - Abbreviation for “positions”.
PTFE - Abbreviation of polytetrafluorethylene. This is the
most commonly used dielectric (insulator) used in
professional coaxial connectors.
QPL - Qualified Parts List. Parts approved to
MIL-C -390 12 specification.
Receptacle - A term used to describe a connector
a
ssembly usually bulkhead or PCB mounted.
Return Loss - A reason for loosing RF energy due to
signals being reflected due to a mismatch in a
transmission line.
RF Leakage - The RF power lost from a transmission line
or device. Measured in dB.
RG - The traditional prefix for MIL spec coaxial cables.
Screw-on - The mating action of connectors which are
joined using a screw thread (e.g. SMC)
S
ealflex2
T
M
-
Cannon trade name for a flexible microwave
cable assembly which has a performance similar to semi-
rigid cable.
Semi-rigid Cable - A coaxial cable where the outer
conductor is a solid metal tube.
Skin Effect - The tendency of alternating currents to flow
near to the surface of a conductor; this increases
resistance and becomes more marked the higher the
frequency.
SMD - Sometimes used as an abbreviation for slide-on
variants of SMB. This is a misnomer, the
more common
use is for Surface Mount Device.
Snap-on - A term used to describe the mating action of
SMB and SSMB connectors.
Solderless SMA - An SMA connector that can be
connected to semi-rigid cable by compressing the inner
body rather than by soldering (sometimes referred to as
semi-rigid ‘crimp’ connectors).
Stripline - A method of building a microwave circuit. The
circuitry is sandwiched between 2 ground planes.
Sometimes referred to as Tri-plate.
Teflon - DuPont tradename for PTFE.
Tensile Strength - The greatest force a device can
withstand without tearing or pulling apart. This is
frequently the method of determining the effectiveness of
a crimp.
TNC - Thread Nut Connector same size as BNC; the only
obvious difference is the coupling nut.
T
ri-plate - See Stripline.
UG Symbol - Used to indicate a connector made to US
government spec.
V
oltage Standing W
ave Ratio (VSWR) - A way of
expressing the resultant loss of power as a result of signal
reflections due to discontinuity
.
60
61
www.ittcannon.com
Dimensions shown in mm (inch)
Specifications and dimensions subject to change
Cannon 50 Ohm Connectors PART NUMBER INDEX
P
art Number Page
050-007-0000220 24
050-024-0000220 24
050-027-0000220 24
050-043-0000220 25
050-045-0000220 25
050-047-0000220 25
050-074-6201310 35
050-424-3188220 31
050-424-3196220 31
050-428-3188220 31
050-428-3196220 31
050-443-0000220 31
050-445-0000220 31
050-451-0000220 32
050-453-0000220 32
050-622-9188890
8
050-622-9875890
8
050-627-9188890 8
050-627-9875890 8
050-628-9188890 8
050-628-9875890 8
050-645-4528890 10
050-645-4540890 10
050-645-4575890 10
050-645-9009890 10
050-651-0000310 11
050-653-0000310 11
050-673-0000890 12
050-674-0000890 12
050-674-6302310 35
050-674-6324990 36
050-674-6700890 36
050-675-0000890 12
050-675-6705890 36
050-675-6801890
36
050-678-0000890 12
051-027-0000220 21
051-027-3196220
21
051-027-9399220 21
051-043-0000220 22
051-045-0000220 22
051-047-0000220 22
051-075-0000220 21
051-424-3188220 29
P
art Number Page
051-427-3188220 29
051-443-0000220 29
051-445-0000220 30
051-452-0000220 30
055-607-2003890 9
055-607-9172890 9
055-607-9173890 9
055-611-3702890 9
055-611-3703890 9
055-939-9019AR6 33
055-939-9029AR6 33
055-939-9039AR6 34
055-939-9049AR6 34
055-939-9059AR6 34
055-939-9069AR6 34
065-9AA-0300000
39
065-9AA-0500000
39
065-9AA-0750000 39
065-9AA-1000000 39
065-9AA-1500000 39
065-9AA-2000000 39
065-9AA-2000000 39
065-9AS-0500000 39
065-9AS-1000000 39
065-9AS-2000000 39
065-9SS-0500000 39
065-9SS-1000000 39
065-9SS-2000000 39
065-9SS-3000000 39
A50-624-9188890 8
A50-624-9875890 8
A51-424-3196220 29
A51-427-3196220 29
A51-428-3188220 29
A51-428-3196220
29
A51-428-3875220 29
A51-451-0000220 30
A51-453-0000220
30
B50-051-0000220 26
B50-051-9019220 26
B50-053-0000220 26
B50-053-9019220 26
B50-328-3188220 24
B50-328-9399220 24
P
art Number Page
B51-024-0000220 21
B51-024-3196220 21
B51-024-9399220 21
B51-051-9029220 23
B51-053-0000220 23
B51-053-9029220 23
B51-328-3188220 21
B51-328-3196220 21
B51-328-9019AU0 21
B51-328-9399220 21
B51-351-0000220 23
F50-E22-9141000 15
F50-E22-9142000 15
F50-E22-9188000 15
F50-E22-9875000 15
F50-E27-9188000
16
F50-E27-9875000
16
F50-E28-9141000 15
F50-E28-9142000 15
F50-E28-9188000 15
F50-E28-9875000 15
F50-E51-0000000 16
F50-E53-0000000 16
F55-E07-2003000 17
F55-E07-9172000 17
F55-E07-9173000 17
F55-E11-3702000 17
F55-E11-3703000 17
K29263 59
K29265 59
T0854/10D 59
T0854/12/E 59
T0854/12/Z4 59
T0854/7/G 59
T0854/7/M
59
T0854/8/C 59
T0854/9/A 59
T0854/9/C
59
T1025/- 58
T1025/1 58
T1025/9 59
T4897 58
T4898 58
T4899 58
