Cannon 50 Ohm Connectors COAXIAL TERMINATORS
TTEERRMMIINNAATTOORRSS
Two Legs at Front, Standard
Part Number
055 - 939 - 9039AR6
055 - 939 - 9049AR6
Cable Numbers
RG178/U, 196/U
RG174/U, 179/U, 188/U, 316/U
5.33
(.210)
ø6,20
(.244)
2,54
(.100)
3,94
(.155)
4º
R
EF
1,09
(
.043)
5,08
(
.200)
Mounting Plan T (Page 40)
Assembly Instruction BBAI-1203 (Page 53)
Two Legs at Front, Surface and Vertical Mount
Part Number
055 - 939 - 9059AR6
055 - 939 - 9069AR6
Cable Numbers
RG178/U, 196/U
RG174/U, 179/U, 188/U, 316/U
9,52
(.375)
ø6,20
(.244)
3,05
(.120)
5,08
(.200)
5.92
(.233)
Mounting Plan T (Page 40)
Assembly Instruction BBAI-1203 (Page 53)
34
www
.ittcannon.com
Dimensions shown in mm (inch)
Specifications and dimensions subject to change
SMA Jack to SMC Plug
Part Number
050 - 074 - 6201310
6.35
(.250)
A/F HEX
18.64
(.734)
SMA
JACK
SMC
PLUG
RP RP
10.92
(.430)
SMA Jack to SMB Plug
P
art Number
050 - 674 - 6302310
6.35
(.250)
A/F HEX
17.86
(.703)
SMA
JACK
SMB
PLUG
RP RP
14.22
(.560)
Between Series Adaptors are widely used for high efficiency
t
ransitions between various types of RF coaxial connectors.
They are used for connecting test equipment to systems
employing a different type connector or they are used as a
component in electronic equipment where it is desirable to
have one type of connector for external connections and
another type for internal connections.
All Between Series Adaptors are designed for lowest VSWR
characteristics up to the frequency limits of the connector
types involved. All popular types of miniature, subminiature
and micro-miniature designs are available.
The designs shown here are not the entire range. If you
require a style not shown, please contact our Customer
Service group.
Cannon 50 Ohm Connectors BETWEEN SERIES ADAPTORS
35
www.ittcannon.com
Dimensions shown in mm (inch)
Specifications and dimensions subject to change
Key Features
• Rugged construction
• Precision performance
• Low VSWR
•
Ready to use - no assembly required
Cannon 50 Ohm Connectors BETWEEN SERIES ADAPTORS
S
MA Slide-On Plug to SMA Standard Jack
Adaptor - Straight (Connector Saver)
Part Number
050 - 674 - 6324990
2
1.49
(.846)
11.89
(.468)
9.60
(.378)
SMA
SLIDE-ON
PLUG
ø10.31
(.406)
5.54
(.218)
A/F
2 FLATS
SMA
JACK
N Plug to SMA Jack
Part Number
050 - 674 - 6700890
31.75
(1.250)
17.02
(.670)
ø0.76
(.030)
3 LOCKWIRE
HOLES
N PLUG
17.45
(.687)
A/F
2 FLATS
ø21.21
(.835)
MAX
14.27
(.562)
A/F
2 FLATS
SMA
JACK
N Bulkhead Jack to SMA Jack
P
art Number
050 - 675 - 6705890
34,54
(1.360)
23,32
(.918)
2,29
(.090)
N JACK
13,41
(.528)
A/F
2 FLATS
20,62
(.812)
A/F HEX
19,05
(.750)
A/F HEX
SMA
JACK
BNC Bulkhead Jack to SMA Jack
Part Number
050 - 675 - 6801890
14.27
(.562)
A/F HEX
35.53
(1.320)
20.40
(.803)
11.18
(.440)
RP
BNC
JACK
17.45
(.687)
A/F HEX
SMA
JACK
VSWR:
1.10 + .01f (GHz) DC - 12.4GHz
1.10 + .016f (GHz) 12.4 - 18 GHz
VSWR:
1.06 + .005f (GHz) DC - 12.4GHz
1.06 + .010f (GHz) 12.4 - 18 GHz
Mounting Plan Z (Page 40 ) Panel Thickness 3,18 (.125) max.
Mounting Plan GG (Page 40)
P
anel Thickness 6,35 (.250) max.
36
www
.ittcannon.com
Dimensions shown in mm (inch)
Specifications and dimensions subject to change
