Assembly Instructions AI-98 (P age 42) D D I I R R E E C C T T S S O O L L D D E E R R T T Y Y P P E E C C A A B B L L E E C C O O N N N N E E C C T T O O R R S S F F O O R R S S E E M M I I - - R R I I G G I I D D C C A…
Cannon 50 Ohm Connectors PRECISION SMA
CCRRIIMMPP TTYYPPEE CCAABBLLEE CCOONNNNEECCTTOORRSS FFOORR FFLLEEXXIIBBLLEE CCAABBLLEE
Straight Plug, Non-Captive Contact
P
art Number
050 - 622 - 9188890
050 - 622 - 9875890
Cable Numbers
RG174/U, 316/U
RD316
Straight Plug, Captive Contact
Part Number
A50 - 624- 9188890
A50 - 624 - 9875890
Cable Numbers
RG174/U, 316/U
RD316
Assembly Instructions AI-703 (Page 51)
17,78
(.700)
25,91
(1.020)
17,91
(.705)
7,92
(.312)
A/F HEX
Assembly Instructions AI-90 (Page 41)
Mounting Plan W (Page 40)
Assembly Instructions AI-227 (Page 46)
Right Angle Plug, Captive Contact
Part Number
050 - 628- 9188890
050 - 628 - 9875890
Cable Numbers
RG174/U, 316/U
RD316
17,15
(.675)
13,59
(.535)
12,07
(.475)
Bulkhead Jack, Captive Contact
Part Number
050 - 627- 9188890
050 - 627- 9875890
Cable Numbers
RG174/U, 316/U
RD316
25,65
(1.010)
11,43
(.450)
7,92
(.312)
A/F HEX
Assembly Instructions AI-102 (Page 43)
The surface finish on these products is passivated stainless
steel. For gold plated versions change last three digits of
the the part number from 890 to 310.
8
www
.ittcannon.com
Dimensions shown in mm (inch)
Specifications and dimensions subject to change
Assembly Instructions AI-98 (Page 42)
DDIIRREECCTT SSOOLLDDEERR TTYYPPEE CCAABBLLEE CCOONNNNEECCTTOORRSS FFOORR SSEEMMII--RRIIGGIIDD CCAABBLLEE
Assembly Instructions AI-302 (Page 48)
Assembly Instructions AI-252 (Page 47)
*Center conductor of cable is used as contact
Straight Plug without Center Contact*
Part Number
055 - 607- 2003890
Cable Numbers
RG402/U
11,18
(.440)
Ø3,61
(.142)
MIN
Straight Plug with Center Contact
Part Number
055 - 607- 9172890
055 - 607 - 9173890
Cable Numbers
RG405/U
RG402/U
A
2,20 (.088)
3,60 (.142)
11,18
(.440)
ØA
Right Angle Plug
Part Number
055 - 611- 3702890
055 - 611- 3703890
Cable Numbers
RG405/U
RG402/U
A
2,20 (.088)
3,60 (.142)
17,15
(.675)
13,59
(.535)
7,62
(.300)
ØA
MIN
The surface finish on these products is passivated stainless
steel. F
or gold plated versions change last three digits of
the the part number from 890 to 310.
Cannon 50 Ohm Connectors PRECISION SMA
9
www.ittcannon.com
Dimensions shown in mm (inch)
Specifications and dimensions subject to change
Cannon 50 Ohm Connectors PRECISION SMA
ALL FLANGE MOUNT RECEPTACLES HAVE
CAPTIV
A
TED CONT
ACTS
FFLLAANNGGEE MMOOUUNNTT RREECCEEPPTTAACCLLEESS
Flange Dimensions for Flange Mount
Receptacles and P
anel Jacks
Straight Jack, Stub Contact, Extended Dielectric
Square Flange
050 - 645 - 9009890
Narrow Flange
050 - 645 - 4540890
Part Numbers
Straight Jack, Solder Pot Contact, Flush Dielectric
Square Flange
050 - 645 - 9019890
Narrow Flange
Contact Customer Service
Part Numbers
Straight Jack, Tab Contact, Flush Dielectric
Square Flange
050 - 645 - 4575890
Narrow Flange
050 - 645 - 4528890
Part Numbers
Ø4,11
(1.62)
Ø1,27
(.050)
27,43
(1.080)
14.99
(.590)
1,65
(.085)
9.53
(.375)
Ø1,27
(.050)
Ø0,76
(.030)
MIN
14,61
(.575)
9,53
(.375)
1,65
(
.065)
0,27 x 1,27
(.005 x .050)
2,54
(.100)
9,53
(
.375)
1,85
(.065)
Ø2,59
(.102)
2 POSNS
Ø2,59
(.102)
4 POSNS
12,70
(.500)
6,64
(.340)
15,88
(.625)
12,22
(.481)
5,66
(.223)
Square Flange Narrow Flange
The surface finish on these products is
passivated stainless steel. F
or gold plated
versions change last three digits of the the part
number from 890 to 310.
10
www
.ittcannon.com
Dimensions shown in mm (inch)
Specifications and dimensions subject to change
