P P R R I I N N T T E E D D C C I I R R C C U U I I T T B B O O A A R R D D J J A A C C K K S S SMC PCB preferred styles feature stepped legs. This allows the jacks to be raised from the surface of the PCB, thereby preve…

BBUULLKKHHEEAADD JJAACCKKSS
Mounting Plan V (Page 40)
Mounting Plan V (Page 40)
Mounting Plan V (Page 40)
Straight Bulkhead Jack, Solder Pot,
Mounting Nut outside Panel
Part Number
050 - 043 - 0000220
15,10
(
.594)
10,80
(.425)
6,35
(.250)
A/F HEX
Straight Bulkhead Jack, Solder Pot ,
Mounting Nut inside Panel
Part Number
050 - 045 - 0000220
15,10
(.594)
6,96
(.274)
6,35
(.250)
A/F HEX
10-32 UNF-2A
Right Angle Bulkhead Jack, Solder Pot,
Mounting Nut inside Panel
Part Number
050 - 047 - 0000220
14,96
(.589)
9,45
(.372)
5,72
(.225)
19,35
(.762)
7,92
(.311)
10-32 UNF-2A
Cannon 50 Ohm Connectors SMC
25
www.ittcannon.com
Dimensions shown in mm (inch)
Specifications and dimensions subject to change

PPRRIINNTTEEDD CCIIRRCCUUIITT BBOOAARRDD JJAACCKKSS
SMC PCB preferred styles feature stepped legs. This allows the jacks to be raised from the surface of the PCB, thereby
preventing the accumulation of soldering fluids and foreign bodies. A single piece conductor overcomes the problem of
internal joint separation during continuous wave/flow soldering operations.
Straight PCB Jack, 1,00 (.039) square legs
Part Number
B50 - 051 - 0000220
3,99
(.157)
7,49
(.295)
Ø1,00
(.039)
1,00
(.039)
4 POSNS
6,41
(.252)
Straight PCB Jack, 0,81 (.032) square legs
Part Number
B50 - 051 - 9019220
3,99
(.157)
7,49
(.295)
Ø1,00
(.039)
0,81
(.032)
4 POSNS
0
,61
(.024)
6,41
(.252)
Right Angle PCB Jack, 1,00 (.039) square legs
Part Number
B50 - 053 - 0000220
13,80
(.543)
10,62
(.418)
8,69
(.342)
5,56
(.219)
3,94
(.155)
Ø1,00
(.039)
6,41
(.252)
0.61
(.024)
1,00
(.039)
4 POSNS
Right Angle PCB Jack, 0,81 (.032) sq Legs
Part Number
B50 - 053 - 9019220
13,80
(.543)
10,62
(.418)
8,69
(.342)
5,56
(.219)
3,94
(.155)
Ø 1,00
(.039)
6,41
(.252)
0,61
(.024)
0,81
(.032)
4 POSNS
Mounting Plan A (Page 40)
Mounting Plan B (Page 40)
Mounting Plan A (P
age 40)
Mounting Plan B (Page 40)
Cannon 50 Ohm Connectors SMC
www
.ittcannon.com
26

This range of 50 ohm microminiature radio frequency
connectors is suitable for both military and commercial
equipment operating at frequencies up to 4 GHz (SSMB)
a
nd 12.4 GHz (SSMC). They provide a choice of Snap-on
(SSMB) or Screw-on (SSMC) and are available for a wide
range of flexible cables.
SSMC connectors are used where a positive mechanical
engagement is required and where space permits the
use of torque wrenches. SSMB connectors are quick
disconnect versions of the SSMC and are used in
applications where limited space prohibits the use of
torque wrenches or when components or modules must
be quickly changed to keep down time to a minimum.
NOTES
1) Inside diameter of female contact to meet VSWR, mating characteristics and
connector durability
, when mated with a 0,36 - 0,38 (.014 - .015) diameter male
contact.
2) Must meet the force to engage and
disengage when mated with its
mating part.
0,84
(.033)
MIN
0,00
(.000)
MIN
RP
PLUG JACK
1,78
(.070)
MAX
0,84
(.033)
MIN
SEE NOTE
# 2
Ø1,35
(.053)
MAX
Ø4,83
(.190)
MAX
Ø1,37
(.054)
MIN
Ø2,67
(.105)
MAX
Ø0.36/0.38
(.014/.015)
0,00
(.000)
MIN
0,84
(.033)
MAX
RP
1,91
(.075)
MIN
1,91
(.075)
MIN
CLOSED ENTRY CONTACT
3,10
(.122)
3,10
(.122)
MIN
0,00
(.000)
MIN
6,40 UNF-2B
THREAD
3,96
(.156)
A/F HEX
2,29
(.090) MAX
2,29
(.090)
MIN
2,29
(.090)
MIN
6,40 UNF-2A
THREAD
2,29
(.090) MAX
5,08
(.200) MAX
Ø1,35
(.053)
MIN
Ø2,57
(.101)
MIN
Ø1,37
(.054)
MIN
Ø2,54
(.100)
MAX
Ø 0,36/0,38
(.014/.015)
4,32
(.170)
MIN
3,00
(.118)
0,84
(.033)
MAX
0,00
(.000)
MIN
0,00
(.000)
MIN
JACKPLUG
RP
RP
CLOSED ENTRY
CONTACT
SSMB (SNAP-ON)
SSMC (SCREW-ON)
MMAATTIINNGG IINNTTEERRFFAACCEE
Cannon 50 Ohm Connectors SSMB / SSMC
27
www.ittcannon.com
Dimensions shown in mm (inch)
Specifications and dimensions subject to change
Key Features
• Small size
• Low mass
• Close packing density
• Used in airborne applications
