Notes Chapter 1: Machine Configuration Preliminary 1-16 CP-842E/842ME Operator ’ s Guide
Panel Transport System
XY-table
The XY-table moves the panel forward and back & left and right to precisely
place the part at the placement point specified in the production program. The
panel is also moved up and down to align with the height of the part so that
undue stress is not exerted on the part.
In / Out-conveyor
The in-conveyor receives panels from the previous machine. The in-lifter then
rises and the panel is delivered to the in-carrier.
The out-conveyor unloads finished panels to the next machine. The out-lifter
rises and the out-carrier receives a panel. When the out-lifter descends a panel
is then delivered to the out-conveyor.
In / Out-carrier
The in-carrier receives a panel from the in-conveyor and delivers it to the XY-
table.
The out-carrier receives a panel from the XY-table or and delivers it to the out-
conveyor.
C84INT011E
Handle
In-conveyor
XY-table
In-carrier
Out-carrier
Out-conveyor
Chapter 1: Machine Configuration
Preliminary
1-15CP-842E/842ME Operator’s Guide
Notes
Chapter 1: Machine Configuration
Preliminary
1-16 CP-842E/842ME Operator’s Guide
Chapter 2
Starting and Stopping the Machine
2.1 Starting the Machine
2.2 Prior to Cutting the Power
2.3 Cutting the Power
