Chapter 6 Finishing Production 6.1 Stopping Automatically Upon Completion of the Scheduled Production Quantity 6.2 Stopping Automatically After Current Panel is Completed 6.3 Stopping Production Automatically After All P…
Notes
Chapter 5: Stopping the Machine
Preliminary
5-4 CP-842E/842ME Operator’s Guide
Chapter 6
Finishing Production
6.1 Stopping Automatically Upon Completion of the Scheduled
Production Quantity
6.2 Stopping Automatically After Current Panel is Completed
6.3 Stopping Production Automatically After All Panels Remaining in
the Machine are Completed
Preliminary
6-1CP-842E/842ME Operator’s Guide
The machine stops automatically once the scheduled production quantity is
produced. Refer to, "Setting the Scheduled Production Quantity" in section
3-2 regarding the procedure for setting the scheduled production quantity.
Note: Once the scheduled production quantity for a production program has
been completed, clear the production quantity counter to use the produc-
tion program again. Refer to "Clearing the Production Quantity Count"
in section 8-14 regarding this procedure.
During the course of production it is possible to automatically stop the
machine once the panel(s) currently on the XY-table is completed and
unloaded to the out-conveyor.
Procedure
1. Press [Finish Current Panels] while production on the machine
is in progress.
2. Once production of the panel(s) currently being produced (panel
on the XY-table) is finished and the panel is unloaded to the out-
conveyor, the machine will automatically stop.
Note: If a panel is not unloaded to the next machine and the panel is left on the
out-conveyor, panels on the out-carrier and XY-table cannot be unloaded.
Remove the panels on the out-conveyor in order.
6.2 Stopping Automatically After Current
Panel is Completed
6.1 Stopping Automatically Upon Completion
of the Scheduled Production Quantity
Chapter 6: Finishing Production
Preliminary
6-2 CP-842E/842ME Operator’s Guide
