Chapter 3 Preparing for Production 3.1 Setting the Operation Mode 3.2 Production Programs 3.3 Device T ables 3.4 Parts 3.5 Machine Preliminary 3-1 CP-842E/842ME Operator ’s Guide
3. Press the START button.
4. Once the selected D-axis moves to its escape position press
[Close] to return to the [Main] screen.
The operations in the previous section must be carried out prior to turning off
the machine power.
Procedure
1. Press EMERGENCY STOP.
2. Press the [Power OFF] button on the display.
3. Press [OK] in the message box.
Shutdown processing then begins.
4. The final Windows screen displays following shutdown process-
ing, then a timer is used to turn off the power automatically.
CAUTION
Do not press the SYSTEM ON button or the [Restart] but-
ton on the display, while the timer is active.
That completes the normal shutdown procedure. The power light is still on,
but it is not necessary to turn off the power at the breaker unless maintenance
work is required, or when the machine is to be left idle for an extended peri-
od. In these cases, the UPS should be deactivated, and the power should then
be turned off at the breaker. (Refer to the CP-842E/842ME Mechanical
Reference manual for detail.)
2.3 Cutting the Power
Chapter 2: Starting and Stopping the Machine
Preliminary
2-4 CP-842E/842ME Operator’s Guide
Chapter 3
Preparing for Production
3.1 Setting the Operation Mode
3.2 Production Programs
3.3 Device Tables
3.4 Parts
3.5 Machine
Preliminary
3-1CP-842E/842ME Operator’s Guide
Setting the Operation Mode
The machine operation mode must be set to "Production" in order to place
parts on a panel.
<Explanation of operation mode>
Production: This is the mode used for regular production.
Idle: The idle modes must only be used when there
are no parts loaded in the device slots
employed in the production program. The
idle modes are used for warning up the
machine and are not used for production.
Idle operation with loading: The loading and unloading of panels has been
added to the standard idle operation mode.
Operation must be performed without parts
being loaded to the device slot specified by
the program.
Idle operation without pickup: Operates in the same manner as the standard
idle mode except that pickup is not
performed.
Pass: Pass mode is used when the machine is not
used in current production. In pass mode the
machine simply acts as a conveyor, moving
the panel on to the next machine in the line.
Procedure
1. From the [Main] screen select [Operation] to display the
[Operation] screen.
2. Among three modes; [Prodution], [Idle], [Pass], set the operation
mode to [Production].
3. Press [Close] to return to the [Main] screen.
3.1 Setting the Operation Mode
Chapter 3: Preparing for Production
Preliminary
3-2 CP-842E/842ME Operator’s Guide
