1 - 19 www.asm-smt.com Standard Nozzles in the 20xx Series (Ceramic) 2028 L = 16.000 mm Tip: Ø 0.600 mm Item no. 03073195
1 - 18
www.asm-smt.com
Standard Nozzles in the 20xx Series (Ceramic)
2003
L = 16.000 mm
Tip: 0.900 x 0.500 mm (LxW)
Item no. 03054153
2004
L = 15.000 mm
Tip: 1.700 x 1.200 mm (LxW)
Item no. 03054915
2005
L = 15.300 mm
Tip: 0.400 x 0.200 mm (LxW)
Item no. 03060015
2006
L = 16.500 mm
Tip: 0.440 x 0.350 mm (LxW)
Item no. 03054154
2007
L = 16.000 mm
Tip: 1.400 x 0.660 mm (LxW)
Item no. 03057850
2009
L = 19.475 mm
Tip: 0.600 x 0.350 mm (LxW)
Item no. 03116635
1 - 19
www.asm-smt.com
Standard Nozzles in the 20xx Series (Ceramic)
2028
L = 16.000 mm
Tip: Ø 0.600 mm
Item no. 03073195
1 - 20
www.asm-smt.com
Standard Nozzles in the 20xx Series (TPU)
2020
L = 12.500 mm
Tip: Ø 7.000 mm
Item no. 03056002
2021
L = 9.000 mm
Tip: Ø 7.000 mm
Item no. 03059698
2057
L = 15.000 mm
Tip: Ø 7.000 mm
Item no. 03070280
2038
L = 11.000 mm
Tip: Ø 4.000 mm
Item no. 03059921
2039
L = 11.000 mm
Tip: Ø 5.000 mm
Item no. 03059989
