1206 [3.2x1.6x0.8] 105 1206 /Description of bulkcase feeder [3.2x1.6x1.8] 1050 1210 [3.2x2.5x1.7] 106 1812 [4.5x3.2x1.6] 110 2010 [5.0x2.5x1.6] 111 2220 [5.7x5.0x1.7] 112 2 - 5 www.asm-smt.com

2 pin components C&P20A/M CPP C&P20 P/M2 Twin Head

Component shape

[LxWxH (mm)]

file

Nozzle types

0603

[1.6x0.8x1.0]

102

0603/Description of

bulkcase feeder

[1.6x0.8x1.0]

1020

0805

[2.0x1.25x1.3]

103

0805/Description of

bulkcase feeder

[2,41,2541,3]

1030

2 - 4

www.asm-smt.com

1206

[3.2x1.6x0.8]

105

1206/Description of

bulkcase feeder

[3.2x1.6x1.8]

1050

1210

[3.2x2.5x1.7]

106

1812

[4.5x3.2x1.6]

110

2010

[5.0x2.5x1.6]

111

2220

[5.7x5.0x1.7]

112

2 - 5

www.asm-smt.com

2 pin components C&P20A/M CPP C&P20 P/M2 Twin Head

Component shape

[LxWxH (mm)]

file

Nozzle types

Ceramic Resonator

[7.0x2.8x2.8]

1200

Micro-Melf

[2.0x1.2x1.2]

200

Mini-MELF

[3.5x1.4x1.4]

201

Maxi-MELF

[5.9x2.2x2.2]

202

2 - 6
