Mini-MELF Diode SOD 80 [3.4x1.6x1.6] 203 MELF Small Diode Thick SOD 87 [3.6x2.0x2.0] 204 Maxi-MELF Diode / LL-41 [5.0x2.8x2.7] 205 2 - 7 www.asm-smt.com
2 pin components C&P20A/M CPP C&P20 P/M2 Twin Head
Component shape
[LxWxH (mm)]
CS
file
Nozzle types
Ceramic Resonator
[7.0x2.8x2.8]
1200
Micro-Melf
[2.0x1.2x1.2]
200
Mini-MELF
[3.5x1.4x1.4]
201
Maxi-MELF
[5.9x2.2x2.2]
202
2 - 6
www.asm-smt.com
Mini-MELF
Diode SOD 80
[3.4x1.6x1.6]
203
MELF Small Diode
Thick SOD 87
[3.6x2.0x2.0]
204
Maxi-MELF
Diode / LL-41
[5.0x2.8x2.7]
205
2 - 7
www.asm-smt.com
PLCC/SOJ components C&P20A/M CPP C&P20 P/M2 Twin Head
Component shape
[LxWxH (mm)]
CS
file
Nozzle types
SOJ 24/b8.6
[15.88x8.66x3.5]
800
SOJ 26/b8.6
[17.15x8.66x3.5]
801
SOJ 28/b8.66
[18.41x8.66x3.5]
802
SOJ 28/b9.8
[18.42x9.78x3.5]
803
SOJ 28/b18.42
[18.42x11.18x3.5]
804
5 - 6
