00196645-02_JG_ CP20P CP20A CPP TWIN HEAD Nozzles_en.pdf - 第62页

SO components C&P20A/M CPP C&P20 P/M2 Twin Head Component shape [LxWxH (mm)] CS file Nozzle types DIL 4 [4.8x9.7x4.8] 570 DIL 6 [8.6x10.0x4.4] 571 DIL 8 [9.3x10.0x4.4] 572 SO 8 _high_OK8 [4.9x6.0x3.2] 582 4 - 8 …

SO 32X

[21.1x13.8x2.5]

524

SO 40X

[26.2x13.65x2.4]

525

SO 40Y

[26.2x14.25x2.5]

526

TSSOP 20

[6.5x6.4x1.4]

541

4 - 7

www.asm-smt.com

SO components C&P20A/M CPP C&P20 P/M2 Twin Head

Component shape

[LxWxH (mm)]

file

Nozzle types

DIL 4

[4.8x9.7x4.8]

570

DIL 6

[8.6x10.0x4.4]

571

DIL 8

[9.3x10.0x4.4]

572

SO 8_high_OK8

[4.9x6.0x3.2]

582

4 - 8

www.asm-smt.com

TSOP 24_20

[16.0x6.0x1.2]

600

TSOP I 24

[20.0x6.0x1.0]

601

TSOP 32

[20.0x10.1x1.0]

602

TSOP 40

[20.0x10.1x1.2]

603

TSOP I 48

[20.0x12.0x1.2]

604

4 - 9
