PLCC/SOJ components C&P20A/M CPP C&P20 P/M2 Twin Head Component shape [LxWxH (mm)] CS file Nozzle types PLCC 20 [9.85x9.85x4.35] 700 PLCC 28 [12.35x12.35x4.35] 701 5 - 2 www.asm-smt.com
PLCC/SOJ Components and Standard Nozzles
5 - 1
www.asm-smt.com
PLCC/SOJ components C&P20A/M CPP C&P20 P/M2 Twin Head
Component shape
[LxWxH (mm)]
CS
file
Nozzle types
PLCC 20
[9.85x9.85x4.35]
700
PLCC 28
[12.35x12.35x4.35]
701
5 - 2
www.asm-smt.com
PLCC 44
[17.55x17.55x4.35]
702
PLCC 52
[20.05x20.05x4.6]
703
PLCC 68
[25.15x25.15x4.6]
704
