IFS-NX Product Specifications
24
6-1-4 New installation configuration for IFS-NX Ver. 3.1 or earlier (DB2 Ver. 9.7.5)
6-1-4-1 Server PC specification (the number of machines to be connected to the system: 1 to 10)
Table 6-1-4-1 Server PC specifications (Number of machine units: 1 to 10 units)
Recommended specification
Function
CGS/CGSDW/CGSCX database
Cogiscan Web Server (for Configurator, POI and installation)
Cogiscan Web Server (for Reports)
Cogiscan Web Server (for CAMX Message Broker)
Cogiscan Data Warehousing Service
CPU
Quad Core CPU 2.00 GHz or higher
RAM
4 GB or more (XP, Win7 32 bits, Win2003 32 bits, Win2008 32 bits)
6 GB or more (for other OS)
HDD
300 GB RAID1 HDD x 2 sets *1
DVD-ROM
1 unit or more
Screen size
15-inch monitor or bigger
Interface
Standard mouse and keyboard
100 BASE-TX/10 BASE-T - capable, LAN connector (RJ-45) ×1
USB 2.0×1
OS *2
Windows XP Professional SP2 or later (32 bits/64 bits)
Windows 7 Professional SP1 or later (32 bits/64 bits)
Windows 2003 Server Standard SP2 or later (32 bits/64 bits)
Windows 2008 Server Standard SP2 or later (32 bits)
Windows 2008 Server R2 Standard SP1 or later (64 bits)
Firewall
- The following ports need to be opened:
80 (Cogiscan Web Server), 7654 (Cogiscan PTU Shell Server),
50000 (IBM DB2),
56277 (Cogiscan CIMS Server), and56278 (Cogiscan TTC Server)
- The following programs need to be opened:
\Program Files\Cogiscan\Server\Web Server\bin\cgsserver.exe
\Program Files\Cogiscan\Server\ttc\ttc.exe
\Program Files\Cogiscan\Server\ttc\orb\orb.exe
DB2
DB2 Express-C Edition V9.7.5 (Free)
The maximum number of
connectable client PCs
10 units *2
Uninterruptible power
system
Approximately 60 minutes at 100 VA, 70 W (APC Smart-UPS 700 or
equivalent)
*1 Four sets of 300 GB as physical HDDs are needed in total because two sets are needed to
configure the RAID1. Configuration to create the drives C and D in each RAID1 is recommended.
*2 For Windows XP/7, this number indicates how many devices having an IP address other than an
access point, a label printer and an MPC can be connected to the system.
IFS-NX Product Specifications
25
6-1-4-2 Server PC specification (the number of machines to be connected to the system: 11 to 25)
When the number of machines connected to the system is from 11 to 25, a dual-server is included
in the system configuration.
Table 6-1-4-2 Server PC specifications (Number of machine units: 11 to 25 units)
Recommended specification
First PC
Second PC
Function
CGS/CGSCX database
Cogiscan Web Server (for
Configurator, POI and installation)
And Cogiscan Web Server (for
CAMX Message Broker)
CGSDW database
Cogiscan Web Server (for Reports)
Cogiscan Data Warehousing Service
CPU
Quad Core CPU 2.00 GHz or higher
Dual Core CPU 2.00G Hz or higher
RAM
6GB or more
HDD
300GB RAID1 HDD x 2 sets
Fast SATA/SAS HDD (10K or 15K
RPM) *1
1TB RAID1HDD x 2 sets *1
DVD-ROM
1 unit or more
Screen size
15-inch monitor or bigger
Interface
Standard mouse and keyboard
100BASE-TX/10BASE-T - capable, LAN connector (RJ-45) ×1
USB 2.0×1
OS *1
Windows 2003 Server Standard SP2 or later (64 bits)
Windows 2008 Server R2 Standard SP1 or later (64 bits)
Firewall
- The following ports need to be opened:
80 (Cogiscan Web Server), 7654 (Cogiscan PTU Shell Server)、50000 (IBM
DB2), 56277(Cogiscan CIMS Server), 56278 (Cogiscan TTC Server)
- The following programs need to be opened:
\Program Files\Cogiscan\Server\Web Server\bin\cgsserver.exe
\Program Files\Cogiscan\Server\ttc\ttc.exe
\Program Files\Cogiscan\Server\ttc\orb\orb.exe
DB2
DB2 Express-C Edition V9.7.5 (Free)
The maximum number
of connectable client
PCs
15 units
Uninterruptible power
system
Approximately 60 minutes at 100 VA, 70 W (APC Smart-UPS 700 or
equivalent)
*1 Four sets of 300 GB (for the first PC) and four sets of 1 TB (for the second PC) as physical HDDs
are needed in total because two sets are needed to configure the RAID1. Configuration to create the
drives C and D in each RAID1 is recommended. No external HDD can be used via a USB port.
IFS-NX Product Specifications
26
Client PC specification
The client PC specification recommended for the IFS-NX is shown below:
One client PC is required at every location where the COI operates.
Each client PC has to be installed in the same network (TCP/IP) as the server PC.
Recommended specification
CPU
Dual Core CPU 2.00 GHz or higher
RAM
4 GB or more
HDD
40 GB HDD
Screen size
15-inch monitor or bigger
Interface
Standard mouse and keyboard
LAN connector (RJ-45) x 1 for 100BASE-TX/10BASE-T
Internet
Windows shall be able to be updated (This is applied to only some environment of Windows 10). *1
OS
Windows 7 Professional SP1 or later (32 bits/64 bits)
Windows 10 Professional or later (32 bits/64 bits)
Windows 2008 Server Standard SP2 or later (32 bits)
Windows 2008 Server R2 Standard SP1 or later (64 bits)
Windows 2012 Server R2 Standard or later (64 bits)
Windows Server 2016 (64bits)
Firewall
- The following ports need to be opened:
Output: 80 (Cogiscan Web Server), 50000 (IBM DB2), 56277 (Cogiscan CIMS Server)
Input: 56270 (Cogiscan Support)
C:\Program Files\cogiscan\platform\jre\bin\Javaw.exe
*1 The environment that allows Windows to be updated may be required depending on combination of the
language of the OS and that of the COI in order to install the corresponding language pack and
supplementary fonts.
Other network requirements
A fixed ID addresses and network connection are required for each server, a Client PC, an Intelli:
Trolley Pool, a label printer, and a wireless LAN access point. However, a dynamic IP address is
also applied to for client PC.
A fixed IP address and network connection is required for each mounter that is equipped with an
Intelli: Trolley Pool.
When you use Windows 10, the environment allowing Windows to be updated may be required
depending on the language of the OS and that of the COI. See the table below to install the
language pack and supplementary fonts corresponding to the language used with the COI. After
setup, the language used with the COI may be added to the system in some cases. Therefore, it
is recommended to maintain the Internet environment even after setup.
Table 6-3-1 Combination of the OS and the COI requiring installation of the corresponding language pack
OS name
Language
pack name
Windows 10
Japanese
editio
n
Windows 10
English edition
Windows 10
Chinese
edition
Windows 10
Korean edition
Windows 10
other
language
edition
Other
Windows
Language
used with the
COI
Japanese
Japanese pack
✔
✔
✔
✔
English
English
Chinese
Simplified Chinese
Traditional Chinese
✔
✔
✔
Korean
Korean
✔
✔
✔
✔
Spanish
Spanish
German
German
French
French
Portuguese
Portuguese
Antivirus software
Virus Buster (Trend Micro) is recommended as antivirus software.
