5.7. Control
This section describes Control item in the pop-up window displayed by clicking ETC Setup button on the main screen.
Field Name
Field Description
Pad Verification
Button Control
• Default
- This item is selected to pass to following Defect Pad by clicking Next button after selecting GOOD/BAD of
Defect Pad on Defect View, Defect Review, Easy Use.
• View Next Defect Automatically On Click
- This item is selected to pass automatically to following Defect Pad once clicking GOOD/BAD on Defect
View, Defect Review, Easy Use.
PASS / NG Button
Control
• Default
- This item is selected to activate NG / PASS button from the beginning of Defect PCB on Defect View, Defect
Review, Easy Use.
• Activate PASS button after Reviewing all defects
- This item is selected to activate PASS button after reviewing all Defect Pad on Defect View, Defect Review,
Easy Use.
• Activate PASS button after Reviewing [] defects
- This item is selected to activate PASS button after reviewing the setting Defect Pad on Defect View.
• Activate PASS button after Verifying all defects
- This item is selected to activate PASS button after verifying all defects as GOOD /BAD on Defect View,
Defect Review, Easy Use.
• Activate PASS / NG button after Reviewing all defects
- This item is selected to activate NG / PASS button after reviewing all defects on Defect View, Defect
Review, Easy Use
• Activate PASS / NG button after Verifying all defects
- This item is selected to activate NG / PASS button after verifying all defects as GOOD /BAD on Defect View,
Defect Review, Easy Use.
• Disable PASS if defects are more than []
- This item is selected to disable PASS button on Defect View when number of Defect Pad is more than set
value.
- With Message: When PASS button is disabled, the message box will be popped-up.
- Defect Limit Type: This item is selected to set PASS Limit type for all PCB or Panel.
• Automatic selection after reviewing all defects
- Select this item for automatically selecting NG / PASS button of Defect PCB after reviewing all defects when
clicking Next button on Defect Pad on Defect View, Defect Review, Easy Use.
• Automatic selection after verifying all defects
- Select this item for automatically selecting NG / PASS button of Defect PCB after verifying Defect Pad when
clicking GOOD / BAD button on Defect Pad on Defect View, Defect Review, Easy Use.
NG / PASS Button
Verification Data Type
Select this option when MES System is used. (“Use MES System” should be checked and Defect Queue option
should be unchecked.) The data (PAD ID, information of Good / Bad Pad, PCB verification) is saved on Ram
Disk vData folder.
Use Defect Review
Short Key
Select this for using SPC Plus Defect Review short key. (When button is disabled, short key is unusable.)
• Enter Key (Defect Review NG button)
• Space Key (Defect Review PASS button)
• ← control Key (Defect Review Previous button)
• → control Key (Defect Review Next button)
• F1 (Defect Review Bad button)
• F2 (Defect Review Good button)
• = or + (2D Image Zoom In button)
• _ or – (2D Image Zoom Out button)
Refresh Defect
Review Rack Data
This option is selected to refresh Defect Review when DVQ is emptied after clicking NG / PASS button.
Linkage Pass Button
of Block Tolerance
This option is selected to disable PASS button limited to operator when defect number is more than set tolerance
value.
Display User Login
Window Before
Verification
This option is selected to log into Defect View on 3D Inspection System.
5.8. Bad Mark Display Option
This section describes Bad Mark Display Option in the pop-up window displayed by clicking ETC Setup button on the main screen.
Field Name
Field Description
Without “X” Mark
This option is selected for not marking X when Bad is marked.
“+” Mark
This option is selected to mark Bad Mark as +.
