1.3. Option This section describes the it ems displayed by clicking the Option o n the main screen. Field Name Field Description OutSide Racks Sets the setting related to a rack when a rack is connected to the machine . …

Use JPG

Sets the settings related to saving 2D images of a job where defects occur in the *.jpg format.

When this is selected, the 2D images of a job where defects occur are saved in the *.jpg format.

• Change: Click this to specify the path where the corresponding data is to be saved.

 Caution: This button is available only when Use JPG is selected.

• Folder Style: Selects the style of a folder where images are saved. Three styles are available as listed below

- Barcode: When this is selected, the folder name is automatically specified as the barcode of the PCB.

- Auto Increment: When this is selected, the folder name is started from a specified number and

automatically increased from the starting number. Therefore, it is useful when you want to know the

number of the PCB being inspected.

Data Folder

Click this to specify the path where the corresponding data is to be saved.

• Change: Click this to specify the path where the corresponding data is to be saved. Generally, the pre-

defined path is used.

Buffer Result Folder

Click this to specify the path where NG Buffer data is to be saved.

• Change: Click this to specify the path where NG Buffer data is to be saved.

1.2. Remote

This section describes the items displayed by clicking the Remote on the main screen.

Field Name

Field Description

Use Net Monitor

Sets the Net Monitoring Program to use.

• Server IP: Input the Net Monitoring Server IP address.

• Load Rack Grid Count: Sets the Rack Grid number of Machine Rack Buffer Information.

• Use IPAD Net Monitor: This item is selected to use Net Monitor Program on IPAD.

• iniFile Path: Sets the readable file folder on IPAD, when Net Monitor is used by IPAD.

Export Multi Line

Monitoring XML

Click this to export the XML data file, when Multi line monitoring is used.

1.3. Option

This section describes the items displayed by clicking the Option on the main screen.

Field Name

Field Description

OutSide Racks

Sets the setting related to a rack when a rack is connected to the machine.

When this is selected, the rack connected to the machine can be used.

• Timer: When this is selected, it is available to set the time taken from appearance and automatic

disappearance of Defect View. Enter the display time of Defect View.

• Rack: Sets the type of racks interworking with the machine and whether or not to use call function.

- NG Rack[FA]: Select this when Young-jin FA’s machine is used as NG racks.

- Multi Rack[FA]: Select this when Young-jin FA’s machine is used as Multi racks.

- Multi Rack[famecs]: Select this when Famecs’s machine is used as Multi racks.

- Multi Rack[FA] with PC: Select this when Young-jin FA’s machine is used as Multi racks.

- Multi Rack [KH FA]: Select this when Ki-hung FA’s machine is used as multi racks.

- Dual: Select this when Dual Lane machine is used with rack.

- 10+: Select this when racks are used more than 10.

- Use Call function: When this is selected, the call function can be used. Click Call button in the UI (or

OUT button of the machine); the PCB is moved to the repair conveyor. This is only for the case of

Young-jin FA’s Multi racks.

- Use DVC Clear: When this is selected, clear all racks with ‘Out’ signal.

• Use Comm: Sets the settings related to interworking rack connections.

- Rack Num: Enter the number of interworking racks.

- Comm Setting: Enter the communication type.

- Comm Port: Enter the Comm port number.

- Pre Buffer Comm port: Enter the Comm port number. This is used when the buffer rack is interworking

with the previous process of the machine.

- use Delimiter: Select this when you use delimiter.

Defect Queue

With this item, it is available to manage ‘Defect Review’ function via SPC Plus.

This is available when the machine has multi-rack or its repair conveyor is at the end of machine.

When this is selected, the defects of a PCB loaded on the machine are shown via a rack or a PC (remote

PC) linked to the repair conveyor.

• Local: Select this when you check the defects via a PC mounted on the machine.

 Caution: Do not select this function when you use ‘Defect Review’ function via the remote PC.

• Combo box under Local: Select the use of the conveyor.

- Rack Buffer: Select this when the conveyor is used for the rack buffer.

- Repair Conv: Select this when the conveyor is used for the repair conveyor.

SQL Sever

Sets the settings required for saving data in the SQL Server.

When this is selected, you can set the settings related to saving data in the SQL Server.

• DB Name: Specifies the name of database to be used. When this is blank, the system automatically

creates the database name or the existing name is used as it was.

• User ID: Specifies the SQL Server user ID.

• PassWord: Specifies the SQL Server user password.

• Server IP: Specifies the IP address of the SQL Server.

• Create DB : Click this button to create a new database.

• Use Wait Save Done: Wait until the previous PAD inspection save done.

• Use Pop-up Message: Sets the message window pops up when SQL server becomes unconnected.

PPO Using

This item is selected to optimize Previous Printer.

Defect Analysis

For more information, refer to Defect Analysis manual.

Machine Name

Specifies the ordered Machine Name when Auto Export is selected.

Machine Model

Specifies the ordered Machine Model type when Auto Export is selected.

Online Trend

Sets how many PCBs should be analyzed for defect trend analysis.

• Max Check Cnt: Enter the number of PCBs as a trend analysis unit.

Server Stencil

When this is selected, it is available to manage the stencil lifecycle via a server.

 Caution: For more information, refer to Server Stencil section in the manual.

• Job Link: When this is selected, it is available to use the ‘Job Link’ function using the barcode of the stencil.

• Server: Enter the IP address of a server which will manage the stencil lifecycle.

FOV Optimize

Sets the optimizing type.

• Group by Panel: FOV optimizing is performed per panel.

• Reoptimized by Distance: This option is selected to optimize the order between corresponding FOV after

FOV Optimized.

• Search by X Axis: The base of FOV optimizing is changed from the Y-axis to the X-axis.

- Dummy FOV: This is for warping compensation. When this is selected, it is available to specify the

virtual FOV in the middle point of two FOVs. This is used when the distance between two FOVs is long.

- Non Fixed: This item is selected not to use Dummy FOV when Z-tracking is not used.

Click ‘Change JOB LED Parameter’ button on Vision tab of Zebra Setup for setting Z-tracking.

• Local Fiducial Optimize: FOV optimizing is performed as regarding the local fiducial.

Use SPC Real Time Mode

Sets this to use Real Time Mode on SPC Plus.

• SPC Real Time Multi Chart: Select this item to use Save Path of Real Time Multi Chart.
