SIPLACE Pro V13.1 / Software Version Description 05/2016 Edition
8
2.3 Licenses
The available licenses are listed in the following table.
License
Type
Factory Single Object Floating Lines
SIPLACE Pro Server / Desk (includes OIS /
SIS)
SIPLACE Pro – Machine Connection
SiCluster
SiCluster Professional
SiCluster Professional – Machine
Connection
SiCluster Multiline – Machine Connection
Split Table Mode – Machine Connection
SIPLACE Traceability – Machine
Connection
SIPLACE Vision Teach Station
Whispering Down The Line
Automatic Program Download (PCB-
Barcode)
Station Wise Download – Machine
Connection
Borrow Performance – Machine
Connection
Heavy Board Option – Line Connection
Reading Barcode recognition with PCB
Camera
Notice: This license is required for each
station in the line or, alternatively to this, an
installed barcode reader.
Alternative Components
Random Setup
Whispering of Barcodes
Long Board Option – Machine Connection
(with station software version < 709)
Long Board Option up to 850 mm –
Machine Connection
(with station software version 7xx)
Long Board Option up to 1500 mm –
Machine Connection
(with station software version 709 and
higher)
Notice: The license is required for each
station in the line.
SIPLACE Pro V13.1 / Software Version Description 05/2016 Edition
9
SIPLACE LED Pairing – Machine
Connection
Flexible Dual Lane – Machine Connection
Bound
Table 2-1: Available Licenses
Definition of the License Types
Factory
This license type is valid for the entire production run and is not assigned to a license server.
Single
This license type is valid in connection with a (single) station.
Object
This license type is bound to an object, in this case to the machine id. The license is unbound
until the first download to a station which requires this license type. Thereafter the license is
permanently bound to the machine id of this station.
Floating
This license type is fetched from a license server by the application and then released again
when the application is terminated. However, the number of licenses on the license server is
limited.
Lines
This license type is assigned to the placement line.
SIPLACE Pro V13.1 / Software Version Description 05/2016 Edition
10
3 Prerequisites
System requirements
The Support Media included in the installation package checks the necessary system
requirements of your system and installs these. Amongst others e.g. Microsoft .NET
Framework, the License Manager and the Error Reporting tool.
The use of the Support Media V2.3 is obligatory.
The system requirements (supported operating systems and database variants) and an
overview of the interoperable products can be found in the SIPLACE Support Media 2.3
SIPLACE Pro requires an NTFS partition for the installation. FAT or FAT32 file systems are not
supported.
3.1 Supported Station Software Versions and Machine Types
Station Software
Version
Machine Types
709 DX-series: DX1, DX2, DX4
SX-series: SX1/SX2, SX1/SX2 V2, SX4
X-series: X2, X3, X4, X4i
X-series S: X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA3, CA4
TX-series: TX1, TX2, TX2i
708 DX-series: DX1, DX2, DX4
SX-series: SX1/SX2, SX1/SX2 V2, SX4
X-series: X2, X3, X4, X4i
X-series S: X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA3, CA4
707 DX-series: DX1, DX2, DX4
SX-series: SX1/SX2, SX1/SX2 V2, SX4
X-series: X2, X3, X4, X4i
X-series S: X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA3, CA4
605 D-series: D1, D2, D3, D4
X-series: X2, X3, X4
