3 Calibration Functions User ’s Manual Test Program S ITEST Software Version 403.xx Edition 12/97 3 - 2

User’s Manual Test Program SITEST 3 Calibration Functions

Software Version 403.xx Edition 12/97

3 - 1

3 Calibration Functions

NOTE

The heads and gantries must be referenced prior to the performance of the calibration functions.

For a complete calibration of the machine, the test program offers the possibility to start all calibration func-

tions from the "Calibrate entire machine" setting box with the aid of the Calibrate machine... functions (see

section 3.2, Fig. 3.2.1).

However, it is also possible to start the calibration functions individually from the corresponding displays. The

functions for the placement station SIPLACE 80S-20 must be performed on both

gantries.

A complete description of the performance of the individual calibration functions is contained in the respective

sections of this chapter.

3 Calibration Functions User’s Manual Test Program SITEST

Software Version 403.xx Edition 12/97

3 - 2

User’s Manual Test Program SITEST 3 Calibration Functions

Software Version 403.xx Edition 12/97 3.1 Preparation for the Performance of the Calibration Functions

3 - 3

3.1 Preparation for the Performance of the Calibration

Functions

●

In the main view click on the Overall reference run button to have all gantry and head axes perform a

reference run.

●

Make sure that a type 720 nozzle is attached to all (center) sleeves of the revolver heads, and a type

416 nozzle is attached to the IC head of SIPLACE 80F

NOTE

When you perform the calibration of the machine, the gantry that is not currently required will auto-

matically be moved to the park position.

●

Place the calibration tool into the "calibration piece pocket" (see Fig. 3.12.1).

NOTE

The calibration tool must be absolutely free of contamination and is to be placed into the "calibration tool

pocket" with the imprint of the fiducial structure facing down.

●

In the main view select the desired gantry by clicking on the corresponding icon.

NOTE

If the calibration activities are performed using the Calibrate machine... function, a selection of the gantry

is not required.
